MITSUBISHI GT1665M-VTBD New and Original High quality

GT1665M-VTBD

The GT1665M-VTBD model is an 8.4-inch TFT color LCD touch screen human-machine interface device designed specifically for industrial automation scenarios. It has high resolution (VGA 640 × 480 pixels) and 65536 color display capabilities. It uses a high brightness, wide viewing angle TFT LCD screen to ensure clear display effects in complex industrial environments. The device is equipped with an analog resistive touch panel that supports precise touch operations, with a sensitive response and durability of over 1 million times, meeting the high-frequency interaction needs of industrial sites. It has a built-in 15MB user storage space, supports capacity expansion through SD memory cards, is compatible with GOT2000 series software, and can achieve fast reading, writing, and backup of engineering data and logs. In terms of interfaces, Ethernet, RS-232, RS-422/485, and USB host/device ports are standard, supporting multi protocol communication and collaborative control. It can simultaneously connect to devices such as PLC, barcode readers, serial printers, and is compatible with video/RGB units to achieve multimedia data transmission and device status visualization. In addition, this model has a protection level of IP67F, with dust-proof and splash proof capabilities, and can operate stably in the temperature range of -20 ℃ to 60 ℃. It is suitable for industrial scenarios such as mechanical manufacturing, packaging, and chemical engineering, providing a stable and reliable human-machine interaction experience.

Technical specifcations for GT1665M-VTBD

Display parameters

Screen size: 8.4-inch TFT color LCD display screen, designed with high brightness and wide viewing angle, suitable for complex lighting conditions in industrial environments.

Resolution: VGA (640 × 480 pixels), meeting the requirements of industrial monitoring for image clarity.

Display color: 65536 colors, supporting rich color expression, suitable for complex interfaces and animation display.

Perspective range: 80 degrees left and right, 80 degrees up and 60 degrees down, allowing operators to clearly view screen content from multiple angles.

2、 Touch parameters

Touch mode: Analog resistive touch panel, supporting precise touch operation, responsive and durable for over 1 million times, suitable for high-frequency interaction needs in industrial sites.

3、 Storage parameters

User storage capacity: Built in 15MB storage space, supporting capacity expansion through SD memory cards to meet large-scale data storage needs.

4、 Interface parameters

Ethernet interface: supports simultaneous connection of multiple devices to achieve collaborative control and data exchange.

Serial interface: Built in RS-232, RS-422/485 interfaces, compatible with multiple industrial communication protocols, can connect to devices such as PLCs and barcode readers.

USB interface: equipped with USB host and USB device ports, supporting engineering data transfer, log reading, and peripheral connection (such as mouse, keyboard).

Video/RGB unit: compatible with video signal input and RGB output, supports multimedia data transmission and device status visualization.

5、 Power supply and installation parameters

Power type: DC24V power supply, suitable for industrial power supply environment.

Installation type: panel installation type, compact structure, external dimensions of 241 (width) × 190 (height) × 52 (depth) mm, weight 1.7kg, easy to integrate and deploy.

Protection level: IP67F， It has dust-proof and splash proof capabilities, and can operate stably within the temperature range of -20 ℃ to 60 ℃.

6、 Extended Function Parameters

Brightness adjustment: Supports multiple levels of brightness adjustment to meet the operational needs under different lighting conditions.

Communication compatibility: Compatible with industrial network protocols such as CC Link and CC Link IE, supporting multi-channel communication.

Data backup and recovery: Supports saving (backup) program, parameter, and other data of programmable controller CPU to GOT's SD memory card and USB storage. When the programmable controller fails, it can be written back (restored) to the program in batches.
