MITSUBISHI HGJR103BJK Servo Motor
Description
Servomotor HG Series, Power 1 kW; Torque 3.18 Nm, Max. Torque 9.55 Nm
Technical Data
Series：MELSERVO-J4
Type：HG-JR
Power Supply (V)：200
Rated Capacity (kW)：1
Inertia：LOW INERTIA
Rated Torque (Nm)：3,2
Maximum Torque (Nm)：9,6
Rated Speed (rpm)：3.000
Inertia (kg*cm2)：2,65
Brake：NO
Shaft Type：STRAIGHT SHAFT
Current Type：AC
Encoder Resolution (p/rev)：4.194.304
Maximum Speed (rpm)：6.000
Protection Class：IP67
Encoder Type：22-BIT
