MITSUBISHI GT1665M-VTBA New and Original High quality

GT1665M-VTBA

The GT1665M-VTBA model is an 8.4-inch TFT color LCD touch screen human-machine interface product designed specifically for industrial automation scenarios. Its core advantage lies in the use of a high brightness, wide viewing angle TFT LCD display, which can present 65536 rich colors and clear images with a resolution of 640 × 480, ensuring a high-quality visual experience even in complex lighting environments. The product is equipped with an analog resistive touch panel with a service life of over 1 million times, which can accurately respond to operation instructions and meet the high-frequency and high reliability interaction needs of industrial scenarios.

This model supports AC 100-240V wide voltage input, adapts to various industrial power environments, and has passed IP67 protection level certification. It has dust-proof and splash proof capabilities and can operate stably in a wide temperature range of -20 ℃ to 60 ℃. In terms of storage, it has a built-in 15MB user storage space and supports expansion, which can meet the needs of large-scale data storage. The interface configuration covers Ethernet, RS-232, RS-422/485, and USB host/device ports, compatible with industrial communication protocols such as CC Link and CC Link IE, and supports multi protocol collaborative control with devices such as PLC and barcode readers. It is also compatible with video/RGB units to meet the needs of multimedia data transmission and device status visualization. With its compact structure and high protective performance, this product is widely used in industrial fields such as mechanical manufacturing, packaging, and chemical engineering, providing stable and reliable human-machine interaction solutions for automated production lines.

Technical specifcations for GT1665M-VTBA

Display parameters

Display type: TFT color LCD display screen (high brightness, wide viewing angle)

Screen size: 8.4 inches

Resolution: 640 × 480 pixels (VGA)

Display color: 65536 colors

Backlight color viewing angle: 80 degrees left and right, 80 degrees up and 60 degrees down

LCD monomer brightness: 450 cd/m ²

Service life: 43000 hours

2、 Touch parameters

Touch mode: Analog resistive touch screen

Service life: Over 1 million cycles (operating force less than 0.98N)

3、 Storage parameters

Built in flash memory: 15MB (used to store project data and operating system)

Write frequency lifespan: 100000 times

Scalability: Supports expansion up to 57MB

4、 Interface parameters

Bus interface: Supports CC Link CC-Link IE、 Ethernet, FA transparency, high-speed serial and other industrial communication protocols

USB interface: The front panel is equipped with one USB interface, which supports multimedia data transfer and device connection

Video/RGB interface: supports video and RGB signal input, meeting the needs of multimedia data transmission and device status visualization

5、 Power supply and installation parameters

Input power supply voltage: AC 100-240V， Input frequency 50-60Hz

Applicable wire size: 0.75-2mm ²

Dimensions: 241mm (width) x 190mm (height) x 52mm (depth)

Weight: 1.7kg

Installation type: Embedded installation

Panel opening size: 227mm × 176mm (specific size may vary slightly due to installation method)

Protection level: IP67

6、 Environmental parameters

Working environment temperature: Display screen 0 ℃ -50 ℃, outside the display screen 0 ℃ -55 ℃

Storage environment temperature:- 20℃-60℃

Working environment humidity: 10-90% RH, no condensation

Storage environment humidity: 10-90% RH, no condensation

Usage height: below 2000m

Cooling method: self cooling

Insulation resistance: above 10M Ω

Impact resistance: Complies with JIS B 3502 and IEC 61131-2 standards (147m/S ², 3 times in X, Y, Z directions each)
