MITSUBISHI GT1575-VNBA New and Original High quality

GT1575-VNBA

The GT1575-VNBA model product is a high-performance industrial touch screen human-machine interface device designed specifically for complex industrial automation scenarios. It adopts a 10.4-inch TFT color LCD display screen with a resolution of VGA (640 × 480), supports 256 color display, and has clear and delicate images. Combined with high brightness and wide viewing angle characteristics, it can adapt to different lighting and multi angle operation needs. The product is equipped with an analog resistive touch screen that supports multi touch, with a minimum touch key size of 2 × 2 dot matrix and an operating life of over 1 million times, ensuring long-term reliability. In terms of hardware interface, it is equipped with an RS-422 communication module and comes standard with Ethernet, RS-232, and USB interfaces. It supports SD memory card expansion and is compatible with CC Link IE field network communication module, enabling high-speed data exchange and multi device collaboration. This model has 15MB of user storage space, is equipped with GT Works3 development software, supports multimedia function expansion (such as video/RGB units), can smoothly handle high load tasks such as logs, scripts, alarms, etc., and is compatible with all GOT2000 series functions. The protection level reaches IP65F (front), with a working temperature range of 0-55 ℃, suitable for harsh industrial environments, widely used in packaging machinery, automotive manufacturing, energy management and other scenarios, significantly improving the level of equipment intelligence and operational efficiency.

Technical specifcations for GT1575-VNBA

Display parameters

Display size: 10.4-inch TFT color LCD screen, providing high brightness and wide viewing angle display effect.

Resolution: VGA (640 × 480), ensuring clear and delicate images.

Display color: Supports 256 colors or 65536 colors (although there may be slight differences in the description of different materials, they all indicate that it has rich color display capabilities).

Viewing angles: 45 degrees left and right, 30 degrees up and 20 degrees down (some materials mention 85 degrees left and right, up and down, which may vary due to product upgrades or testing conditions).

LCD brightness: ranging from 200 cd/m ² to 400 cd/m ² (there may be differences in brightness expression among different materials, but all support brightness adjustment function).

Brightness adjustment: Supports 4 or 8 levels of brightness adjustment to adapt to different lighting environments.

Display character count: Under 16 dot matrix standard font, it can display 40 words x 30 lines (full width); Under the 12 dot matrix standard font, it can display 55 words x 40 lines (full width).

2、 Touch parameters

Touch mode: Adopting a matrix resistive touch screen, supporting multi touch (up to 2 points pressed simultaneously).

Touch keys: Each screen supports up to 1200 touch keys (30 rows x 40 columns).

Button size: The minimum button size is 16 x 16 dots per button.

Lifespan: Under the condition of operating force below 0.98N, the touch lifespan can reach over 1 million times.

3、 Storage parameters

User memory capacity: Built in flash memory of 5MB (some materials mention 9MB standard memory, expandable to 57MB, may vary due to product upgrades), used to store engineering data and operating systems.

Battery: Equipped with GT15-BAT lithium battery, with a lifespan of approximately 5 years at an ambient temperature of 25 ℃.

Extended storage: Supports CF card expansion, connector shape is TYPEI.

4、 Interface parameters

RS-232: 1 channel, transmission speed includes 115200/57600/38400/19200/9600/4800bps, interface shape is D-sub 9-pin (male head), used for communication with connected devices or connection to personal computers.

USB: 1 channel, maximum transfer speed of 12Mbps at full speed, interface shape of USB Mini-B, used for connecting to personal computers.

Other interfaces: may also include Ethernet interfaces, bus connection interfaces, serial communication interfaces, MELSECNET/H communication interfaces, CC Link communication interfaces, etc. (specific interface configurations may vary due to product upgrades).

5、 Power parameters

Input power supply voltage: AC100~240V (+10%, -15%).

Input frequency: 50/60Hz ± 5%.

Power consumption: Under normal working conditions, it is below 39W, and when the backlight is turned off, it is below 28W.

Impulse current: below 40A (4ms, at maximum load).

Allowable instantaneous stop time: within 20ms.

Noise tolerance: Noise voltage of 1500Vp-p, noise amplitude of 1 μ s, through a noise simulator with noise frequency of 25-60Hz.
