VMPA1-M1H-J-PI
The VMPA1-M1H-J-PI model product is a high-performance two position five way dual electronic control solenoid valve designed specifically for pneumatic control in industrial automation. Its core parameters include: standard rated flow rate of 360 l/min (standardized according to DIN 1343), nominal diameter of 16mm, working temperature range of -20 ° C to 70 ° C, operating pressure of 0.15-0.8 MPa, maximum operating frequency of 5 times/second, effective cross-sectional area of 110mm ², and M7 thread air interface. This product adopts electronic control drive mode, with the characteristics of fast response and stable reliability, suitable for scenarios that require high-precision pneumatic control, such as automotive manufacturing, textile machinery valve island control, and other fields. Its compact structure and easy installation can significantly improve the operational efficiency and stability of industrial automation systems.
Technical specifcations for VMPA1-M1H-J-PI
Type (channel position): Binary formula
Connection form: Thread
Applicable medium: Air
Flow direction: Unidirectional
Nominal diameter: 16mm
Working temperature:- 20 - 70℃
Number of positions: Two position five way
Operating pressure: 0.15-0.8MPa
Effective cross-sectional area: 110mm ²
Maximum action frequency: 5 times/second
Specification: FESTO solenoid valve VMPA1 VMPA1-M1H-M-PI VMPA1-M1H-J-PI original product
Valve function: Two position five way dual electronic control
Standard rated flow rate (standardized according to DIN 1343): 360 l/min
Gas interface, gas port 1: M7
Drive mode: electronic control
Our Services:
1、All our products are new and orginal, and of good quality
2、Our prices are very competitive.
3、 We have a large quantity in stock, so we could help the customers to get the components which are dificult to get.
4、All inquiries will be valued and will reply in 24.
Packing & Delivery:
1、100% brand New and Original Factory Seal!
2、Warranty:1 year
3、Package: Original packing with cartons.
4、Delivery time: Shipped in 3-7 days after payment
5、All the goods will be tested before shipment
