DNC-63-550-PPV-A
The DNC-63-550-PPV-A model product is a high-performance double acting standard cylinder designed specifically for the industrial automation field. Its cylinder diameter is 63 millimeters, with a stroke of 550 millimeters, in compliance with ISO 15552 standard. It adopts a profile type cylinder structure and has an adjustable pneumatic buffer system (PPV) at both ends, effectively reducing impact and noise and extending service life. This model of product has the following characteristics:
High strength and corrosion resistance: The piston rod is made of high alloy steel material, with a hard chrome plated surface to ensure high strength and corrosion resistance; The cylinder barrel is made of refined aluminum alloy, with a smooth surface treated with anodizing to enhance wear resistance.
Modular design: supports multiple derivative and accessory configurations, such as square piston rods, anti torsion transformation, heat-resistant seals, etc., to meet the needs of different application scenarios.
Efficient sealing and low friction: The piston seal is made of TPE-U (polyurethane) material, ensuring the reliability of bidirectional sealing while reducing friction resistance.
Wide range of working parameters: working pressure range from 0.6 bar to 12 bar, working temperature range from -20 ° C to 80 ° C, suitable for dry compressed air or lubricating medium environments.
This model of product is widely used in industries such as machinery, electronics, packaging, printing, plastics, and robots. It can efficiently complete linear reciprocating motion tasks and is an ideal execution component in automated production lines.
Technical specifcations for DNC-63-550-PPV-A
Specification
model: DNC-63-550-PPV-A
Cylinder type: Double acting standard cylinder
Cylinder diameter: 63 mm
Travel distance: 550 mm
2. Working parameters
Working pressure range: 0.6 bar to 12 bar (or 1 bar to 10 bar, depending on the application)
Working temperature range:- 20 ° C to 80 ° C
Working medium: Dry compressed air (lubricated or unlubricated)
3. Performance parameters
Theoretical force at 6 bar:
Forward journey: 1870 N
Return journey: 1682 N
Mobile mass: 663 g (at 0 mm stroke)
Additional mass factor per 10 mm stroke: 73 g
End impact energy: 0.5 J
Buffer length: 22 mm
4. Sealing and Materials
Sealing material:
Piston seal: TPE-U (polyurethane)
Piston rod seal: NBR (nitrile rubber) or TPE-U
Cylinder material: forged aluminum alloy (anodized treatment)
Piston rod material: High alloy steel (surface plated with hard chromium treatment)
5. Installation and Connection
Installation method: Installed through internal threads or accessories, supporting multiple installation positions
Pneumatic connection: G3/8 (standard threaded interface)
Attachment compatibility: Supports accessories such as proximity switches, sensors, self centering connectors, etc
6. Buffer system
Buffer type: PPV (with adjustable pneumatic buffers at both ends)
Buffer function:
Adjustable buffering at both ends to reduce impact and noise
Auxiliary buffer ring (further absorbing energy at high speed or high frequency)
7. Design and Structure
Design standards: comply with ISO 15552, NF E 49 003.1 (France), UNI 10 290 (Italy) and other standards
Modular design: supports multiple derivative types (such as square piston rod, anti torsion transformation, heat-resistant seal, etc.)
Installation Accessories: Provides a wide range of installation accessories suitable for almost any installation location
8. Environment and Durability
Corrosion resistance level: CRC 2 (moderate corrosion resistance)
Protection level: meets explosion-proof requirements (such as ATEX certification)
Service life: High sealing and low friction design, extending service life
9. Application scenarios
An automated production line suitable for industries such as machinery, electronics, packaging, printing, plastics, and robotics, capable of efficiently completing linear reciprocating motion tasks.
