Festo ADVU-25-50-P-A Compact cylinder Brand new

Festo ADVU-25-50-P-A Compact cylinder

Description

Compact cylinder ADVU-25-50-P-A For proximity sensing, piston-rod end with female thread. Stroke=50 mm, Piston diameter=25 mm, Cushioning=P: Flexible cushioning rings/plates at both ends, Assembly position=Any, Mode of operation=double-acting

Specifications

・Operating medium: Compressed air as per ISO 8573-1:2010 [7:4:4]

・Corrosion resistance class (CRC): 2 - Moderate corrosion stress

・Cylinder Operation Method: Double Acting

・50% less installation space than comparable standards-based cylinders to ISO 15552

・Wide range of variants for customised applications

・Piston rod with female or male thread

・For position sensing

Technical Data

Stroke：25 mm

Piston diameter：50 mm

Piston rod thread：M8

Cushioning：Elastic cushioning rings/plates at both ends

Mounting position：optional

Mode of operation：Double-acting

Piston-rod end：Female thread

Design：Piston Piston rod

Position detection：Via proximity switch

Symbol；00991217

Variants：Piston rod at one end

Operating pressure：0.08 MPa ... 1 MPa

Operating pressure：0.8 bar ... 10 bar

Operating pressure；11.6 psi ... 145 psi

Operating medium：Compressed air to ISO 8573-1:2010 [7:4:4]

Note on operating and pilot medium：Lubricated operation possible (in which case lubricated operation will always be required)

Corrosion resistance class CRC：2 - Moderate corrosion stress

LABS (PWIS) conformity：VDMA24364-B1/B2-L

Ambient temperature：-20 °C ... 80 °C

Impact energy in end positions：0.64 J

Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke：1057 N

Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke：1178 N

Moving mass for 0 mm stroke：112 g

Additional moving mass per 10 mm stroke：16 g

Basic weight for 0 mm stroke：560 g

Additional weight per 10 mm stroke：72 g

Type of mounting：Either:With through-hole  With accessories

Pneumatic connection：G1/8

Material collar screws：Galvanised steel

Material cover：Wrought aluminium alloy

Material dynamic seals：NBR TPE-U(PU)

Material piston rod：High-alloy steel

Material cylinder barrel：Wrought aluminium alloy

Find the perfect accessories to complete your product assembly

DSNU-32- -

QSL-1/8-8

SGS-M20X1,5

GRLA-1/8-B

Our Services:

1、All our products are new and original, and of good quality.

2、Our prices are very competitive.

3、We have a large quantity in stock, so we could help the customers to get the components which are difficult to get.

4、All inquiries will be valued and will reply in 24.

Packing & Delivery:

1)100% brand New and Original Factory Seal!

2)Warranty: 1 year

3)Package: Original packing with cartons.

4)Delivery time: Shipped in 3-7 days after payment

5) All the goods will be tested before shipment.
