SMC AS2201F-02-08S New and Original High quality

AS2201F-02-08S

The AS2201F-02-08S model product is a speed control valve belonging to the AS series. It adopts a push lock design to improve the convenience of needle valve locking operation. At the same time, its large handwheel design further optimizes the operating experience. This product is equipped with specifications of sealant to enhance sealing performance, and supports 360 ° free piping. It can be adapted to various types of fittings to meet different installation needs. In terms of interface design, the air inlet is R1/4 external thread, and the air outlet is compatible with 8mm pipe diameter. At the same time, an R1/4 external thread interface is provided for strong compatibility. This model controls the flow by means of exhaust throttling, which is suitable for adjusting the movement speed of the cylinder in the pneumatic system, especially when the movement speed of the actuator needs to be precisely controlled. Its compact structure and low flow resistance help simplify the airflow circuit and improve system efficiency.

Technical specifcations for AS2201F-02-08S

Infrastructure parameters

Model: AS2201F-02-08S

Series: AS Series

Installation method: Supports various forms such as direct installation, L-shaped bracket installation, DIN rail installation, and holder installation, making it easy to flexibly adapt to different device layouts.

Valve body structure: Adopting a metal valve body elbow design, with a built-in quick change joint structure to enhance the convenience of pipeline connection.

Lightweight design: Compared to early products, it reduces weight by 30% and optimizes equipment integration efficiency.

2、 Performance parameters

Control method: Exhaust throttling flow control, which achieves precise control of cylinder movement speed by adjusting the exhaust flow rate.

Thread size: Both the inlet and outlet use R1/4 external thread interfaces, suitable for standard pneumatic piping systems.

Pipe connection diameter: The air outlet supports a diameter of Φ 8mm, meeting the requirements of conventional piping.

Sealing specification: Standard sealant coating to enhance interface sealing performance and reduce leakage risk.

Flow characteristics: The structure is simple and the resistance is low, which can simplify the design of the airflow circuit and improve the system response speed.

3、 Operating parameters

Pressure range: 0.1-1.0MPa, suitable for most industrial pneumatic system pressure requirements.

Adjustment method: Adjust the flow rate by rotating the handwheel, and gradually close the throttle valve by rotating clockwise.

Adjustment range: The number of adjustment turns should not exceed the set value to avoid damage to the needle valve assembly.

Response characteristics: It is recommended to install near the cylinder to shorten the response time. When the piping volume exceeds the cylinder volume, it may affect the speed control accuracy.

4、 Environmental parameters

Working temperature range: -10 ℃ to 60 ℃, meeting the requirements of conventional industrial environments.

Protective features: Non electrolytic nickel plating surface treatment enhances corrosion resistance and extends service life.

5、 Installation and maintenance parameters

Installation specifications: It is necessary to clean the piping in advance, confirm the fluid flow direction markings, and avoid reverse installation.

Torque standard: After manually pre tightening the joint thread, it is necessary to use tools to add 2-3 turns of tightening.

Sealing management: The sealant applied to the pipe thread can be reused 2-3 times, and excessive tightening may cause the sealant to extrude.

Maintenance points: Regularly check the wear of the needle valve components and avoid using the speed control valve as a shut-off valve.
