MITSUBISHI GT1676M-STBD New and Original High quality

GT1676M-STBD

The GT1676M-STBD model is a high-performance human-machine interface (HMI) device designed for the industrial automation field, with its core function positioned to meet the visual operation and monitoring needs in complex production environments. This product continues the consistent compact and modular design concept of Mitsubishi Electric's GOT series, using a 10.4-inch SVGA (800 × 600) resolution TFT LCD display screen, combined with 65536 color display technology, which can clearly present the operating status and data charts of industrial equipment. Its 4-wire resistive touch screen supports multi touch operation, with sensitive response and a lifespan of over 1 million times. It is also equipped with an IP65F dustproof and waterproof front cover, which can adapt to harsh environments such as dust and oil stains. In terms of hardware, it has a built-in 15MB user storage space and supports CF card expansion. It is compatible with GT Works3 development software and achieves seamless communication with devices such as PLCs and inverters through RS-232, USB, and Ethernet interfaces. It is widely used in industrial scenarios that require high reliability, such as automotive manufacturing, food processing, and energy management.

Technical specifcations for GT1676M-STBD

Display parameters

Screen size: 10.4-inch TFT color LCD screen, meeting the requirements for display device size in industrial scenarios.

Resolution: SVGA (800 × 600 dots), presenting clear and delicate image display effects, making it easy for operators to observe the device's operating status and data.

Display color: 65536 colors, providing rich color expression, can meet the basic needs of color in industrial monitoring, and ensure visual presentation effect.

LCD brightness: 400 cd/m ², and supports brightness adjustment function. Users can flexibly set it according to their actual needs to adapt to different environmental lighting conditions.

Viewing angle: 80 ° up and 60 ° down, providing operators with a good visual experience when viewing screen content from different angles.

2、 Touch parameters

Touch mode: Analog resistive touch screen, with sensitive and stable operation characteristics, can accurately respond to the operator's touch instructions.

Touch life: Under the condition of operating force below 0.98N, the touch life can reach more than 1 million times, with strong durability, which can meet the long-term use needs of industrial equipment.

Touch key count: Each screen supports a maximum of a certain number of touch keys (the specific number is not explicitly mentioned), but it can meet the requirements of complex operation interface design and facilitate operators to perform various functional operations.

Button size: minimum 2 x 2 dots (per touch key) to ensure precise operation and reduce the possibility of misoperation.

3、 Storage parameters

User storage capacity: 15MB, used to store engineering data and operating systems, ensuring normal device operation and storage of user data.

Extended storage: Supports interfaces for SD memory card modules, allows installation of optional SD memory card modules, saves alarm and log data, and meets large-scale data storage needs.

4、 Interface parameters

RS-232: 1 channel, transmission speed includes 115200/57600/38400/19200/9600/4800bps, interface shape is D-sub 9-pin (male head), used for communication with connected devices or connection to personal computers, facilitating data transmission and device connection.

RS-422: Built in RS-422 interface, connector shape is RJ-45 (module jack), supporting device communication and gateway function, and can achieve connection and communication with various industrial equipment.

USB: Includes USB HOST and USB device ports. According to the serial USB (full speed 12Mbps) standard, the connector shape is Mini-B, used to connect to a personal computer, achieve software package data upload, FA transparency function, etc., facilitating device configuration and maintenance.

Ethernet: Standard Ethernet interface, supports simultaneous connection of multiple devices, achieves collaborative control, and improves the overall efficiency and collaboration of industrial automation systems.

Other interfaces: Supports RS-422/485 interface, can connect various FA machines, barcode readers, etc., further expanding the application range of the device.

5、 Power parameters

Input power supply voltage: AC100~240V, able to adapt to a wide range of voltage fluctuations, ensuring stable operation of the equipment in different power supply environments.

Power consumption: The specific value is not explicitly mentioned, but the power consumption is usually low during operation, meeting the energy-saving needs of industrial equipment and reducing operating costs for enterprises.

Allowable instantaneous stop time: within 5ms, it can maintain stable operation in case of brief power interruption, avoid data loss or equipment failure, and ensure the continuity of industrial production.

6、 Structure and protection parameters

Protection level: The front part meets the IP65F standard, and the interior of the panel meets the IP2X standard. It has dustproof and waterproof capabilities and can adapt to harsh industrial environments such as dust and humidity, protecting the internal components of the equipment from external environmental influences.

Dimensions: 316 (W) × 242 (H) × 52 (D) mm, compact structure, easy to install and integrate, saving equipment installation space.

Panel opening size: 302 (W) × 228 (H) mm, convenient for equipment installation on control cabinets and other devices.

Weight: Approximately 2.7KG (excluding installation accessories), easy to handle and deploy, reducing the difficulty of equipment installation and maintenance.

Working temperature range: -10 ℃ to 55 ℃, meeting the temperature requirements of different industrial scenarios, and can work normally in various harsh temperature environments.
