MITSUBISHI GT1675M-VTBD New and Original High quality

GT1675M-VTBD

The GT1675M-VTBD model product is a high-performance industrial human-machine interface device that uses a 10.4-inch TFT color LCD display screen with high brightness and wide viewing angle characteristics. It supports 65536 color display and can clearly present the operating status and data information of industrial equipment. It is equipped with a 4-wire resistive touch screen, supporting multi touch operations, with sensitive response and a lifespan of over 1 million times. It also has an IP67 protection level, which can effectively resist the adverse environmental effects such as dust and water splashes. The device has a built-in 15MB user storage space, supports expanding storage capacity through SD cards, and is compatible with GT Works3 development software. It can seamlessly connect with industrial equipment such as PLCs and inverters, and supports RS-232, RS-422/485, Ethernet, and USB interfaces to meet multi protocol communication requirements. It is widely used in industrial scenarios such as automotive manufacturing, food processing, and energy management that require strict equipment stability.

Technical specifcations for GT1675M-VTBD

Display parameters

Screen size: 10.4-inch TFT color LCD screen, with high brightness and wide viewing angle characteristics, can adapt to complex lighting environments in industrial sites.

Resolution: 640 × 480 dots (VGA), ensuring clear and delicate display content, meeting the basic requirements of industrial monitoring for image quality.

Display color: 65536 colors, providing rich color representation, helping operators accurately identify device status and data information.

Perspective: 88 degrees up, down, left, right, providing a wide viewing angle, making it convenient for operators to view screen content from different directions.

2、 Touch parameters

Touch mode: Adopting an analog resistive touch screen, supporting multi touch operation (specific functions may be limited by application scenarios), with sensitive and stable response.

Touch life: Under the condition of operating force less than 0.98N, the touch life can reach more than 1 million times, with strong durability, which can meet the long-term use needs of industrial equipment.

3、 Storage parameters

User storage capacity: 15MB, used to store engineering data and operating systems, meeting basic data storage requirements.

Extended Storage: Supports expanding storage capacity through SD memory cards, which can store large amounts of data such as alarms and logs, meeting the needs of large-scale data storage.

4、 Interface parameters

Communication interface:

RS-232： Supports multiple transmission speeds for communication with connected devices or connection to personal computers.

RS-422/485： Built in interface, supports multi protocol communication, can connect various FA machines, barcode readers, etc.

Ethernet: Standard interface, supports simultaneous connection of multiple devices, achieves collaborative control, and improves the overall efficiency of industrial automation systems.

USB interface: includes USB HOST and USB device ports, supports transferring engineering data or reading log data through USB storage, and can also be connected to a USB mouse or keyboard for use.

5、 Power parameters

Power type: DC24V， Suitable for DC power supply scenarios, ensuring stable operation of equipment in specific power environments.

Power consumption: The specific power consumption value is not explicitly mentioned, but the power consumption is usually low during operation, meeting the energy-saving needs of industrial equipment.

6、 Structure and protection parameters

Protection level: IP67， Equipped with high protection capability, it can effectively resist the adverse environmental effects such as dust and water splashes, and protect the internal components of the equipment from damage.

Dimensions: 303 × 214 × 49mm, compact structure, easy to install and integrate, saving equipment installation space.

Panel opening size: 289 × 200mm, convenient for equipment installation on control cabinets and other devices.

Main frame color: usually black, in line with the design style of industrial equipment.

Working temperature range: 0 ℃ to 50 ℃ (display screen), 0 ℃ to 55 ℃ (outside the display screen), meeting the temperature requirements of different industrial scenarios.

Our Services:

1、All our products are new and orginal, and of good quality

2、Our prices are very competitive.

3、 We have a large quantity in stock, so we could help the customers to get the components which are dificult to get.

4、All inquiries will be valued and will reply in 24.

Packing & Delivery:

1、100% brand New and Original Factory Seal!

2、Warranty:1 year

3、Package: Original packing with cartons.

4、Delivery time: Shipped in 3-7 days after payment

5、All the goods will be tested before shipment
