MITSUBISHI GT1575-VTBA New and Original High quality

GT1575-VTBA

The GT1575-VTBA model is a high-performance human-machine interface device designed specifically for the industrial automation field. It features a 10.4-inch TFT color LCD display screen, paired with VGA (640 × 480) resolution and 256 color display technology, balancing image clarity and color reproduction capability. Its core configuration includes a matrix resistive touch screen that supports multi touch operation, with a minimum key size of 16 × 16 dot matrix and a touch life of over 1 million times (operation force ≤ 0.98N). With 1200 touch keys per screen, it can efficiently respond to the multi task interaction requirements of complex industrial scenes. This model is equipped with 11MB of user storage space, compatible with GT Works3 1.17T and above development software, supports USB, RS-232, and CF card expansion interfaces, and can flexibly expand storage capacity and achieve communication connections with various devices. In terms of protection, the front of the equipment has reached IP65F dust and water resistance level, and the internal protection level is IP2X. The working temperature range covers 0-55 ℃, and the power input supports DC24V wide voltage (± 25%/-20%), which is suitable for harsh industrial environments such as dust, humidity, and voltage fluctuations. It is widely used in packaging machinery, automotive manufacturing, energy management, and other fields that require strict equipment stability.

Technical specifcations for GT1575-VTBA

Display parameters

Screen size: 10.4-inch TFT color LCD screen, providing high brightness and wide viewing angle display effects, suitable for complex lighting environments in industrial sites.

Resolution: VGA (640 × 480), ensuring clear and delicate images.

Display color: Some materials display 256 colors, while others mention supporting 65536 colors, which can meet the basic color requirements of industrial monitoring while also considering high color reproduction ability.

Viewing angles: 45 degrees left and right, 30 degrees up and 20 degrees down, suitable for multi angle operation needs.

LCD brightness: Supports brightness adjustment function, the specific brightness value varies depending on product configuration or usage environment, and can usually adapt to different lighting conditions.

2、 Touch parameters

Touch mode: Adopting a matrix resistive touch screen, supporting multi touch (up to 2 points simultaneously pressed), the operation is sensitive and stable.

Touch key count: Each screen supports up to 1200 touch keys (30 rows x 40 columns), meeting the multitasking interaction needs of complex industrial scenes.

Button size: The minimum button size is 16 x 16 dots per button to ensure precise operation.

Lifespan: Under the condition of operating force below 0.98N, the touch life can reach more than 1 million times, with strong durability.

3、 Storage parameters

User memory capacity: The built-in flash memory has a capacity of 9MB and is used to store engineering data and operating systems, meeting general industrial application requirements.

Extended storage: Supports CF card expansion, with a TYPEI connector shape, making it convenient for users to backup data and expand storage capacity.

4、 Interface parameters

RS-232: 1 channel, transmission speed includes 115200/57600/38400/19200/9600/4800bps, interface shape is D-sub 9-pin (male head), used for communication with connected devices or connection to personal computers.

USB: Equipped with a USB device port, it supports transferring engineering data or reading log data through USB storage, and can also be connected to a USB mouse or keyboard for use.

Other interfaces: may also include RS-422 interfaces, Ethernet interfaces, etc. (specific interface configurations may vary due to product upgrades) to meet the communication needs of different devices.

5、 Power parameters

Input power supply voltage: AC100~240V, suitable for a wide range of voltage fluctuations, ensuring stable operation of the equipment in complex power grid environments.

Power consumption: Under normal working conditions, the power consumption is relatively low, and the specific value varies depending on the product configuration and usage.

Allowable instantaneous stop time: within 10ms, ensuring that the equipment can maintain stable operation even in the event of a brief power interruption.

6、 Structure and protection parameters

Protection structure: The front part meets the IP65F standard, and the interior of the panel meets the IP2X standard, with dustproof and waterproof capabilities, suitable for harsh industrial environments such as dust and humidity.

Dimensions: 303 (W) × 214 (H) × 49 (D) mm, compact structure, easy to install and maintain.

Weight: Approximately 2.3KG (excluding installation accessories), moderate weight, easy to handle and install.

Our Services:

1、All our products are new and orginal, and of good quality

2、Our prices are very competitive.

3、 We have a large quantity in stock, so we could help the customers to get the components which are dificult to get.

4、All inquiries will be valued and will reply in 24.

Packing & Delivery:

1、100% brand New and Original Factory Seal!

2、Warranty:1 year

3、Package: Original packing with cartons.

4、Delivery time: Shipped in 3-7 days after payment

5、All the goods will be tested before shipment
