MITSUBISHI GT1575-STBA New and Original High quality

GT1575-STBA

The GT1575-STBA model is a high-performance human-machine interface (HMI) product designed specifically for the industrial automation field. It features a 10.4-inch TFT color LCD display with a resolution of SVGA (800 × 600), capable of presenting 65536 colors of high brightness and wide viewing angle images. It supports clear character display of 50 characters x 37 lines (full angle) in 16 dot matrix standard fonts or 66 characters x 50 lines (full angle) in 12 dot matrix fonts, meeting complex monitoring needs. This product is equipped with a matrix resistive touch screen that supports up to 2 simultaneous touches, with a button lifespan of over 1 million times (operating force ≤ 0.98N). Combined with built-in 11MB flash memory and 512KB SRAM (with lithium battery backup), it can stably store engineering data and real-time parameters. Its communication interfaces include RS-232, RS-422/485, and Ethernet, supporting USB and SD card expansion, and can seamlessly interface with PLC, sensors, and other devices to achieve high-speed data exchange. In terms of protection, the front part meets the IP65F standard, the interior of the panel reaches IP2X, and the working temperature range is 0-55 ℃, suitable for harsh industrial environments. The GT Works3 software provides graphical programming and debugging tools, suitable for fields such as packaging machinery, automotive manufacturing, energy management, etc., which can significantly improve the level of equipment intelligence and operational efficiency.

Technical specifcations for GT1575-STBA

Display parameters

Screen size: 10.4-inch TFT color LCD screen, high brightness, wide viewing angle design.

Resolution: SVGA (800 × 600), providing clear and delicate image display.

Display color: 65536 colors, meeting the color reproduction needs of industrial monitoring.

Viewing angle: 85 degrees left, right, up, and down, suitable for multi angle operation needs.

LCD brightness: 400 cd/m ², supports 8-level brightness adjustment, suitable for different lighting environments.

Display character count: 50 characters x 37 lines (full width) in 16 dot matrix standard font, and 66 characters x 50 lines (full width) in 12 dot matrix standard font.

Background light: It adopts cold cathode fluorescent tubes (replaceable), supports backlight off detection function, and can set backlight off time and screensaver time.

Touch parameters

Touch mode: Matrix resistive touch screen, supporting multi touch.

Touch keys: 1900 per screen (38 rows x 50 columns).

Button size: minimum 16 x 16 dots per button.

Simultaneously press: Supports up to 2 simultaneous touches.

Lifespan: Under the condition of operating force below 0.98N, the lifespan can reach more than 1 million times.

Storage parameters

User memory capacity: Built in flash memory of 11MB, used for storing engineering data and operating systems.

Battery: Equipped with GT15-BAT lithium battery, with a lifespan of approximately 5 years at an ambient temperature of 25 ℃.

Extended storage: Supports SD card expansion, connector shape is TYPEI.

Interface parameters

RS-232: 1 channel, transmission speed includes 115200/57600/38400/19200/9600/4800bps, interface shape is D-sub 9-pin (male head), used for communication with connected devices or connection to personal computers.

USB: 1 channel, maximum transfer speed of 12Mbps at full speed, interface shape of USB Mini-B, used for connecting to personal computers.

Expansion interface: Provides 1 channel for the installation of optional function boards, and 2 channels for the installation of communication units/optional units.

Power supply parameters

Input power supply voltage: AC100~240V (+10%, -15%).

Input frequency: 50/60Hz ± 5%.

Power consumption: Under normal working conditions, it is below 39W, and when the backlight is turned off, it is below 28W.

Impulse current: below 40A (4ms, at maximum load).

Allowable instantaneous stop time: within 20ms.

Noise tolerance: Noise voltage of 1500Vp-p, noise amplitude of 1 μ s, through a noise simulator with noise frequency of 25-60Hz.

Voltage endurance: AC1500V between power terminal and ground wire, lasting for 1 minute.

Insulation resistance: The total voltage between the power terminal and the ground wire is DC500V, tested with an insulation resistance meter, and the resistance value is above 10M Ω.

Structure and protection parameters

Protection structure: The front part meets the IP65F standard, and the interior of the panel meets the IP2X standard.

Dimensions: 303 (W) × 214 (H) × 49 (D) mm.

Panel opening size: 289 (W) × 200 (H) mm.

Our Services:

1、All our products are new and orginal, and of good quality

2、Our prices are very competitive.

3、 We have a large quantity in stock, so we could help the customers to get the components which are dificult to get.

4、All inquiries will be valued and will reply in 24.

Packing & Delivery:

1、100% brand New and Original Factory Seal!

2、Warranty:1 year

3、Package: Original packing with cartons.

4、Delivery time: Shipped in 3-7 days after payment

5、All the goods will be tested before shipment
