MITSUBISHI GT1275-VNBA New and Original High quality

GT1275-VNBA

The GT1275-VNBA model is a high-performance industrial touch screen human-machine interface (HMI) product designed specifically for complex industrial automation scenarios. It adopts a 10.4-inch TFT color LCD display screen with a resolution of 640 × 480 pixels, supports 256 color display, can present clear and delicate image effects, and has high brightness and wide viewing angle characteristics, adapting to the operational needs of different angles and lighting conditions. This product supports AC100~240V wide voltage input, built-in 6MB flash memory, and is equipped with USB interface, RS-422/485 interface, and RS-232 interface. It can seamlessly connect with Mitsubishi PLC and other mainstream brand PLCs to achieve high-speed data transmission and equipment monitoring. Its protection level reaches IP67, with dustproof and waterproof capabilities, and a working temperature range of 0-55 ℃, which can adapt to harsh industrial environments. In addition, it supports GT Designer 2 Version 2 software for graphic design, with convenient operation and rich functions. It is widely used in industrial fields such as packaging machinery, textile equipment, and automated production lines, which helps to improve equipment development efficiency and system integration. It is a reliable human-machine interaction solution in industrial automation systems.

Technical specifcations for GT1275-VNBA

Display parameters

Display size: 10.4-inch TFT color LCD screen, capable of presenting clear and delicate images.

Resolution: 640 × 480 pixels, meeting the requirements for image accuracy in the field of industrial automation.

Display color: 256 colors, providing rich color levels and enhancing the visual experience of the user interface.

Viewing angles: 45 degrees left and right, 30 degrees up, and 20 degrees down, making it convenient to view the displayed content from different angles.

Brightness: Approximately 200cd/m ², with 4 levels of brightness adjustment to meet different lighting conditions.

Display size: The display area size is 211.2 (W) × 158.4 (H) mm, and the character display size is 170.9 (W) × 128.2 (H) mm. It can display 40 characters × 30 lines (2 bytes) in 16 point standard font and 53 characters × 40 lines (2 bytes) in 12 point standard font.

2、 Electrical parameters

Input power voltage: Supports AC100~240V (+10%, -15%), 50/60Hz ± 5%, meeting power standards in different regions.

Power consumption: 44VA (4ms) at maximum load, normal operating power consumption is 18W or less, and 15W or less under some operating conditions, with lower power consumption.

Insulation resistance: Apply 1500V AC between the power terminal and the ground wire for 1 minute, and test with an insulation tester. The DC 500V impedance between the power terminal and the ground wire is above 10M Ω.

Noise voltage: 1500 Vpp, noise width 1 μ s, noise frequency 25kHz to 60Hz, measured using a noise simulator.

3、 Storage parameters

User Memory: Built in 6MB flash memory for storing project data and functional operating systems.

Interface support: Built in CF card interface, supporting data expansion and backup.

4、 Interface parameters

RS-422/485 interface: supports high-speed data transmission and can connect various FA devices.

RS-232 interface: used to connect devices such as PLCs and barcode readers to achieve data communication.

USB interface: Built in USB Mini interface, faster upload and download speed, convenient for connecting with personal computers.

Ethernet interface: Supports Ethernet communication to achieve networked monitoring and management.

5、 Protection and structural parameters

Protection level: The panel protection level is IP65 (some information mentions IP67, which may vary due to product batch or configuration differences), with a certain degree of dust and water resistance, and can adapt to harsh industrial environments to a certain extent.

Dimensions: 303 (W) × 214 (H) × 53 (D) mm, compact structure, easy to install and integrate into various industrial equipment.

Panel opening size: 289 (W) × 200 (H) mm, convenient for equipment integration and installation.

Weight: The specific weight may vary due to differences in product configuration or shell material.

Working temperature: 0~55 ℃, suitable for temperature changes in different industrial environments.

Lifespan: The cold cathode fluorescent tube has a lifespan of approximately 52000 hours (operating at an ambient temperature of 25 ℃), and the backlight can be replaced to ensure long-term stable operation.

Our Services:

1、All our products are new and orginal, and of good quality

2、Our prices are very competitive.

3、 We have a large quantity in stock, so we could help the customers to get the components which are dificult to get.

4、All inquiries will be valued and will reply in 24.

Packing & Delivery:

1、100% brand New and Original Factory Seal!

2、Warranty:1 year

3、Package: Original packing with cartons.

4、Delivery time: Shipped in 3-7 days after payment

5、All the goods will be tested before shipment
