KEYENCE IG-1000 New and Original High quality

IG-1000

The IG-1000 model product is a high-precision multifunctional laser micrometer or photoelectric sensor designed specifically for industrial automation scenarios. Its core function is based on CCD laser scanning technology, which can achieve micrometer level precision measurement (resolution up to 1 µ m, repeat accuracy ± 0.05% F.S.), supporting ± 5V/4-20mA analog and NPC/PNP digital output, suitable for dynamic contour detection, outer diameter/thickness measurement, and high-speed production line monitoring. This model adopts a compact metal shell (size approximately 2-8.8mm × 3.7-7.1mm), with a built-in dual position 7-segment LED display screen, IP65 protection level and anti electromagnetic interference capability. It can work stably in a wide temperature range of -50 ° C to+130 ° C (some models), compatible with DIN rail installation, and supporting software for multi-channel data synchronization and edge detection functions. Typical application scenarios include semiconductor wafer positioning, precision inspection of automotive components, and quality control of 3C electronic assembly lines. Its technical parameters may vary due to packaging types (such as 2021+batches), and some models can be extended to 270 ° to detect angles and support non-contact dynamic measurement.

Technical specifcations for IG-1000

Core functions and precision

Measurement principle: Based on CCD laser scanning technology, non-contact measurement is achieved using visible light semiconductor laser (wavelength 660 nm), which complies with IEC/JIS Class 1 laser safety standards.

Detection range: Supports installation distances of 0-1000 mm, with a detection range of up to 10 mm. The minimum detectable object is ø 0.1 mm in high sensitivity mode (set distance of 100 mm) and ø 0.2 mm in standard mode (set distance less than 50 mm).

Accuracy and repeatability: The repeatability accuracy is ± 5 µ m (set distance of 100 mm), ± 10 µ m (set distance of 500 mm), ± 80 µ m (set distance of 1000 mm), and the linearity is F S. ± 0.28% (± 28 µ m), with a temperature characteristic of F S. ± 0.03%/° C (± 3 µ m/° C).

2、 Electrical characteristics

Power Supply Voltage: Supports 10-30 VDC DC power supply, including ripple (P-P) 10%, Class 2 LPS, maximum power supply voltage of 9.5 V (some models), minimum power supply voltage of 3 V (some models).

Power consumption: Under normal mode, it is less than 2700 mW (less than 90 mA at 30 V). Under power-saving function, it can be reduced to 2300 mW (halved) or 2200 mW (all).

Output signal: Supports digital output, analog output can choose ± 5 V, 1-5 V, 0-5 V, 4-20 mA, voltage output range ± 5 V (up to 10 V), output resistance 100 Ω, maximum load resistance 350 Ω, repetition accuracy ± 1 mV (voltage) or ± 1.5 µ A (current), display accuracy F S. ± 0.05% (voltage) or ± 0.25% (current), temperature characteristic F S. /° C ± 0.005% (voltage) or ± 0.01% (current).

3、 Environmental adaptability

Working temperature: Conventional models range from -10 ° C to+50 ° C (without freezing), while some models support -20 ° C to+125 ° C or -50 ° C to+100 ° C.

Relative humidity: 35% to 85% RH (non condensing).

Seismic resistance: 10 to 55 Hz, double amplitude of 1.5 mm, 2 hours for X, Y, and Z axes.

Protection level: The shell protection level is IP67, and the ambient light can withstand 5000 lux of incandescent lamps and 5000 lux of sunlight.

4、 Display and Interface

Display mode: Dual 7-segment LED display screen, upper level red 5 bits, lower level green 5 bits, display range -99.999 to+99.999, display resolution options include 1 µ m, 10 µ m, 100 µ m, and 1000 µ m.

Output interface: The output supports NPN (PNP) open collector x 3ch, less than 30 VDC (power supply voltage), residual voltage less than 1 V (2 V), N.O./N.C. optional, maximum 50 mA/ch, response time 1.96 to 4031.72 ms; edge check output supports NPN (PNP) open collector x 1ch, response time 20 ms.

5、 Installation and Communication

Installation method: Supports DIN rail installation and panel installation. The main module housing/front plate material is polycarbonate, the key top is polyacetal, and the cable is PVC.

Communication function: Supports CC Link and DeviceNet ™、 Ethernet/IP ™、 PROFIBUS DP and other communication protocols (implemented through communication units such as DL-CL1, DL-DN1, DL-EP1, DL-PD1, etc.).

6、 Other characteristics

Response time: Same as the judgment output response time, with a time constant of 10 µ s (90% response, voltage output) or 30 µ s (90% response, current output).

Input function: Supports gain input, reset input, timing input, zero offset input, bank A/B input, laser emission stop input, etc. Input time is greater than 20 ms (some inputs are greater than 2 ms), response delay time is less than 120 ms (non-volatile memory EEPROM is less than 1.5 s).

Our Services:

1、All our products are new and orginal, and of good quality

2、Our prices are very competitive.

3、 We have a large quantity in stock, so we could help the customers to get the components which are dificult to get.

4、All inquiries will be valued and will reply in 24.

Packing & Delivery:

1、100% brand New and Original Factory Seal!

2、Warranty:1 year

3、Package: Original packing with cartons.

4、Delivery time: Shipped in 3-7 days after payment

5、All the goods will be tested before shipment

More Products In Stock:
