KEYENCE N-L20 New and Original High quality

N-L20

The N-L20 model product is a high-performance Ethernet communication unit designed specifically for industrial automation scenarios. Its core functions enable stable data exchange with IEEE 802.3 10BASE-T/100BASE-TX standards through an integrated RJ-45 interface, supporting TCP, UDP, FTP, BOOTP, EtherNet/IP ™、 PROFINET and other mainstream industrial protocols are compatible with Mitsubishi Electric Q series PLC, KV STUDIO, MC protocol, OMRON PLC Link and other multi platform control systems. The product adopts 11 point LED status indicator lights (including sensor head communication, Ethernet link, power supply, and 6 sets of IO port status), built-in 5VDC ± 5% barcode reader dedicated power supply (maximum current 650mA), with 2-point bidirectional voltage input (maximum rated value 26.4VDC, minimum ON voltage 15VDC) and 4-point optical MOS relay output (rated load 30VDC/100mA, residual voltage ≤ 1V, leakage current ≤ 0.1mA when OFF), which can achieve millisecond level signal response and precise industrial equipment linkage control. Its compact design supports DIN rail installation, with a protection level of IP67 (for some interfaces), environmental adaptability covering storage temperatures from -20 ° C to+60 ° C and working temperatures from 0 ° C to+50 ° C. Its seismic resistance has passed 10-55Hz dual amplitude 0.3mm, X/Y/Z three-axis testing for 2 hours each, suitable for high reliability scenarios such as semiconductor wafer traceability, automotive component assembly line monitoring, and 3C electronic production data acquisition. It has also passed UL/CSA certification and can seamlessly integrate with Keyence AutoID Network Navigator software for visual configuration and fault diagnosis.

Technical specifcations for N-L20

1、 Interface and Communication

Interface type: The N-L20 model product is equipped with Ethernet interface (RJ-45) and USB interface (Mini-B), supporting high-speed data transmission.

Communication standards: The Ethernet interface complies with the IEEE 802.3 10BASE-T/100BASE-TX standard, and the USB interface supports USB 2.0 Full Speed.

Supported protocols: including TCP, UDP, FTP, BOOTP, EtherNet/IP ™、 PROFINET, KV STUDIO, MC protocol, OMRON PLC link, etc. can be seamlessly integrated with various industrial control systems.

2、 Display and indication

LED indicator lights: The product is equipped with 11 LED indicator lights, which are used to display the communication status of the sensor head (RD, SD), Ethernet link status (Link), power status (Power, can display multiple colors), IO terminal status (× 6), and error status (Error), making it convenient for users to monitor the device's operating status in real time.

3、 Power Supply and Input/Output

Barcode reader power supply: Provides a stable power output of 5 VDC ± 5%, with a maximum current of 650 mA, connected through a terminal block to meet the power supply requirements of barcode readers and other peripherals.

Input characteristics: Equipped with 2-point bidirectional voltage input (IN1, IN2), the maximum rated input value is 26.4 VDC, the minimum ON voltage is 15 VDC, and the maximum OFF current is 1 mA, suitable for various industrial signal input scenarios.

Output characteristics: Provides 4-point optical MOS relay output (OUT1 to 4), rated load of 30 VDC, 100 mA, leakage current ≤ 0.1 mA when OFF, residual voltage ≤ 1 V when ON, ensuring the stability and reliability of the output signal.

4、 Electrical specifications

Rated power supply voltage: 24 VDC+10%, -20%, suitable for different industrial power supply environments.

Current consumption: ≤ 380 mA, low power consumption, energy-saving and efficient.

5、 Environmental adaptability

Working temperature range: 0 ° C to+50 ° C (without freezing), meeting the working temperature requirements of most industrial sites.

Storage environment temperature range: -20 ° C to+60 ° C (no freezing), convenient for equipment storage and transportation.

Relative humidity: 35% to 85% RH (non condensing), suitable for different humidity environments.

Usage environment: Require dust-free or non corrosive gases to ensure long-term stable operation of the equipment.

Seismic resistance: Through seismic testing from 10 to 55 Hz, double amplitude of 0.3 mm, and 2 hours each in the X, Y, and Z directions, it is suitable for complex industrial environments.

6、 Other characteristics

Weight: Approximately 135 g (excluding connectors), compact in size, easy to install and deploy.

Certification standards: Complies with UL/CSA standards to ensure the safety and reliability of the product.
