KEYENCE CA-CH10R New and Original High quality

CA-CH10R

The CA-CH10R model product is a bending resistant camera cable designed specifically for high-speed dynamic image acquisition scenarios. It adopts a standard length specification of 10 meters, and its core structure achieves high-frequency signal anti-interference ability through a double-layer shielding layer and a high flexibility PVC outer cover. It supports stable transmission of 4K level image sensor data at 10Gbps bandwidth. This model of cable has built-in differential signal pairing technology, which, when combined with the Keyence XG series high-speed vision system, can achieve real-time signal synchronization at a frame rate of 886fps. Its minimum bending radius is 5 times the diameter of the cable, and it can still maintain a signal sensitivity of -101 ± 2dBm within a wide temperature range of -20 ° C to+80 ° C. The product has passed UL certification and complies with China's RoHS environmental standards, compatible with Keyence LumiTrax ™ The light source expansion unit and CA-DXR5 lighting module are widely used in industrial scenarios that require high-frequency robotic arm bending, such as semiconductor wafer inspection and 3D vision positioning,

Technical specifcations for CA-CH10R

basic parameters

Model: CA-CH10R

Length: 10 meters

Type: Buckle resistant camera cable, designed specifically for high-speed dynamic image acquisition scenarios, suitable for industrial automation, machine vision, and other scenarios that require frequent bending.

2、 Performance parameters

Transmission capability: Supports high-frequency signal transmission, with a bandwidth of up to 10Gbps, ensuring high-speed and stable transmission of 4K level image sensor data.

Anti interference capability: Adopting a double-layer shielding layer design, it effectively resists external electromagnetic interference, ensuring the clarity and stability of signal transmission.

Bending radius: The minimum bending radius can reach 5 times the diameter of the cable, meeting the wiring requirements in complex mechanical structures and suitable for the dynamic movement of equipment such as robotic arms.

Working temperature range: -20 ° C to+80 ° C, suitable for various industrial environments.

Signal sensitivity: Maintain a signal sensitivity of -101 ± 2dBm over a wide temperature range to ensure image quality is not affected by the environment.

3、 Protection and Certification

Protection level: The product has passed IP65 protection level certification and has dust and water resistance capabilities, suitable for harsh industrial environments.

Environmental standards: Ensure that the product is harmless to the environment during use.

Other certifications: May have international certifications such as UL certification, CSA certification, etc., to meet the entry requirements of the global market.

4、 Application and compatibility

Application scenarios: Widely used in industrial scenarios such as semiconductor wafer inspection, 3D vision positioning, precision picking and placing of electronic assembly lines, and flexible grasping of food packaging.

Compatibility: Compatible with the Keyence XG series high-speed vision system LumiTrax ™ The light source expansion unit and CA-DXR5 lighting module can be seamlessly integrated with other visual system products from Keyence.

Our Services:

1、All our products are new and orginal, and of good quality

2、Our prices are very competitive.

3、 We have a large quantity in stock, so we could help the customers to get the components which are dificult to get.

4、All inquiries will be valued and will reply in 24.

Packing & Delivery:

1、100% brand New and Original Factory Seal!

2、Warranty:1 year

3、Package: Original packing with cartons.

4、Delivery time: Shipped in 3-7 days after payment

5、All the goods will be tested before shipment
