KEYENCE GT2-75P New and Original High quality

GT2-75P

The GT2-75P model product is a high-precision digital displacement sensor amplifier unit designed for industrial automation detection scenarios. It adopts a panel installation structure and PNP output configuration, compatible with 10-30VDC wide power input (including 10% ripple), and has multi-level display and high response characteristics. Its core functions include a 6+1/2 bit 7-segment LED measurement value display and a dual color 13 level bar LED status indicator, supporting a display range of -1999.999.9 to 1999.999.9 with a resolution of 0.1 μ m. The response time can be configured as 3/5/10/100/500/1000ms (12/20/40/400/2000/4000ms when paired with GT2 Pxxx), and the control output supports five levels of PNP collector open circuit mode (maximum 30V 50mA, residual voltage ≤ 1V). The product's protection level complies with UL/CSA standards, and the main body is made of polycarbonate shell and PVC cable. It has excellent environmental adaptability and can operate stably under conditions of -10 ℃ to+50 ℃ (no freezing) and 35% to 85% RH (no condensation). Its seismic resistance reaches 10-55Hz, with a double amplitude of 1.5mm (2 hours in X/Y/Z directions). When connecting expansion modules, it supports 2-15 cascaded units. The power supply voltage and control output current are automatically adapted according to the number of connections, making it suitable for industrial scenarios such as precision machining and semiconductor manufacturing that require high-precision displacement detection.

Technical specifcations for GT2-75P

Basic specifications

Model and brand: GT2-75P

Output type: PNP output, suitable for various industrial control scenarios.

Installation method: Panel installation, easy to integrate into equipment or control cabinets.

Electrical performance

Power Supply Voltage: Supports 10 to 30VDC, including 10% ripple (P-P), Class 2 standard, suitable for industrial environments with a wide voltage range.

Power consumption:

Maximum 2200mW in standard mode (73.3mA at 30V).

Maximum 1700mW (56.7mA at 30V) in power-saving (environmentally friendly) mode.

Display power: The measurement value display uses 6+1/2 bit 7-segment LED (red), while other displays use 2-color 13 level bar LED (red, green) and are equipped with indicator lights.

Displays and Controls

Display range: -1999.999.9 to 1999.999.9, with a display resolution of up to 0.1 μ m, suitable for high-precision measurement.

Control input: Supports no voltage input functions such as timing, preset, reset, channel input, etc.

Control output: Provides five levels of PNP collector open circuit output, HH/HI/GO/LO/LL, with a maximum of 30V 50mA and a maximum residual voltage of 1V.

Response time: Supports multiple settings such as 3/5/10/100/500/1000ms. When used in conjunction with GT2 Pxxx sensor heads, the response time can be extended to 12/20/40/400/2000/4000ms.

Environmental adaptability

Working temperature: -10 to+50 ° C (no freezing), suitable for various industrial environment temperatures.

Relative humidity: 35 to 85% RH (non condensing), ensuring stable operation even in humid environments.

Seismic resistance: 10 to 55Hz, double amplitude of 1.5mm, 2 hours each in the X, Y, and Z directions, meeting the vibration requirements of industrial equipment.

Material and Structure

Main body shell: Made of polycarbonate material, sturdy and durable.

Touch key: Made of polyoxymethylene material, providing a good operating feel.

Front panel: Made of PET material, displaying measurement data clearly.

Cable: Made of PVC material, it has good flexibility and durability.

Expansion and Connection

Power/I/O cable: connected with a 12 core connector, comes with a connecting cable for easy installation and debugging.

Expansion device: Supports 2 to 15 cascaded units, with limitations on power supply voltage and control output current depending on the number of connected units. For example, when connecting 2 to 8 units, the power supply voltage is 20 to 30VDC, and the maximum controlled output current is 20mA; when connecting 9 to 15 units, the power supply voltage is also 20 to 30VDC, but the maximum controlled output current is 10mA (including the output current of DL-RB1A), and the maximum residual voltage is 1.5V.

other characteristics

Compliant with UL/CSA standards to ensure the safety and reliability of the product.

Display and indicator lights: Equipped with a 2-color 13 level bar LED display and indicator lights, it intuitively displays the measurement status and results.
