KEYENCE EX-V05P New and Original High quality

EX-V05P

The EX-V05P model product is a high-precision and high-speed response PNP digital displacement sensor amplifier unit, designed with M16 × 20mm cylindrical thread, supporting a measurement range of 0 to 5mm and a display range of ± 19999 to+19999. It has a resolution of 1 μ m and a sampling rate of up to 40000 times per second, and can adapt to different material targets such as iron, aluminum, copper, etc. It displays measurement values and out of range warnings in real time through 7-segment dual color LED. Its core functions include tolerance setting (upper/lower limit 2 levels x 4 styles), PNP collector open circuit signal output (maximum 100mA/30V), pulse/alarm output (residual voltage ≤ 1V), and ± 5V analog voltage output (100 Ω resistor). The response time is only 0.075ms, the delay time is 60ms, and it supports 15 measurement modes, 4 sets of judgment value storage, and decimal/display digit adjustment. The product has a protection level of IP67 and excellent environmental adaptability. It can operate stably under conditions of -10 ℃ to+60 ℃ and 35% to 85% RH (no condensation). Its seismic resistance meets 10 to 55Hz and double amplitude of 1.5mm (2 hours in X/Y/Z directions). It is widely used in industrial scenarios such as precision machining and semiconductor manufacturing that require micrometer level displacement detection.

Technical specifcations for EX-V05P

Type and shape:

Type: Amplifier Unit (PNP Type)

Shape: M16 x 20 mm cylindrical, threaded

Measurement and display range:

Measurement range: 0 to 5 mm

Display range: -19999 to+19999

Accuracy and Resolution:

Linearity: ± 0.3% of full scale (F.S.)

Resolution: 1 µ m (average measurement count: 64)

Sampling and display rate:

Sampling rate: Maximum of 40000 samples per second (if using digital filter function, the sampling speed is 20000 samples per second)

Display rate: 20 times/second

Display and Warning:

Display: 7-segment dual color LED

Out of Range Warning: Display ± FFFF

Control input and output:

Control input: PNP, voltage 10 to 30 V

Control output: tolerance setting, upper/lower limit 2-level setting x 4 styles (optional)

Signal output: PNP collector open circuit (HIGH, GO, and LOW), maximum 100 mA (maximum 30 V)

Response and latency time:

Response time: 0.075 ms (at maximum speed)

Delay time: 60 ms

Pulse and alarm output:

Pulse output: PNP, maximum 100 mA (maximum 30 V), residual voltage maximum 1 V (N.O.)

Alarm output: PNP, maximum 100 mA (maximum 30 V), residual voltage maximum 1 V (N.C.)

Analog output:

Output voltage: ± 5V

Resistance: 100 Ω

Response time: 0.075 ms (at maximum speed)

Temperature characteristics:

Temperature characteristics: 0.07%/℃ of full scale (F.S.) (if the measurement range between the sensing head and the target object is within 50%)

Main functions:

Including FLL function, digital filtering function, automatic zeroing function, compensation function, calculation function, measurement mode (15 types), judgment value storage function (4 sets), decimal point position/display digit change function, various error display functions, etc.

Power supply and current consumption:

Rated power supply voltage: 24 VDC ± 10%, pulsation (P-P): maximum 10%

Current consumption: maximum 240 mA

Environmental resistance:

Environmental temperature: 0 to 50 ℃, no freezing

Relative humidity: 35 to 85%, no condensation

Seismic resistance: 10 to 55 Hz, double amplitude of 1.5 mm, 2 hours each in the X, Y, and Z directions

Our Services:

1、All our products are new and orginal, and of good quality

2、Our prices are very competitive.

3、 We have a large quantity in stock, so we could help the customers to get the components which are dificult to get.

4、All inquiries will be valued and will reply in 24.

Packing & Delivery:

1、100% brand New and Original Factory Seal!

2、Warranty:1 year

3、Package: Original packing with cartons.

4、Delivery time: Shipped in 3-7 days after payment

5、All the goods will be tested before shipment
