KEYENCE FU-70TU New and Original High quality

FU-70TU

The FU-70TU fiber optic sensor is a high-precision and highly reliable industrial detection component that uses a red 4-element light-emitting diode as the light source. It has a sensing distance of 2-12mm and supports dual output configurations of NPN/PNP. It can be flexibly installed through a bracket and is suitable for various industrial automation scenarios. Its working voltage range is DC12-24V ± 10%, and the light source has strong stability, which can effectively prevent mutual interference between multiple devices (supporting up to 10 devices working on the same frequency). It also has built-in digital display function, which can display the amount of received light and threshold in real time, making it easy to debug and monitor. This product has a protection level of IP50 (IEC60529 standard), an insulation resistance of over 20M Ω, flexible connection methods, supports wire lead out or energy-saving wiring connectors, and is equipped with an instruction manual as a standard accessory. It has excellent impact resistance (500m/s ², 3 times in X, Y, Z directions), a withstand voltage of AC1000V 50/60Hz for 1 minute, and an environmental humidity adaptation range of 35-85% RH (no condensation), ensuring stable operation in complex industrial environments. With its compact design, high-precision detection, and anti-interference ability, FU-70TU can be widely used in electronic component detection, precision machining, packaging quality monitoring, and other scenarios, significantly improving production efficiency and quality control level.

Technical specifcations for FU-70TU

Basic specifications

Product type: Fiber optic sensor, using red 4-element LED light source

Sensing distance: 2-12mm, suitable for small object detection scenarios

Output configuration: Supports dual output types of NPN/PNP, adaptable to different control circuit requirements

Installation method: Flexible fixation through brackets, compatible with various industrial installation environments

Electrical performance

Power supply voltage: DC12-24V ± 10%, compatible with common industrial power supply systems

Insulation resistance: ≥ 20M Ω, ensuring electrical safety

Anti interference capability: Supports up to 10 devices working on the same frequency, effectively avoiding multi machine interference

Display function: Equipped with a digital display screen, real-time display of light reception and threshold data

Environmental adaptability

Protection level: IP50 (IEC60529 standard), dust-proof design ensures stable operation

Working temperature: -20 ℃ to 130 ℃, covering harsh industrial environments

Humidity range: 35% to 85% RH (no condensation), suitable for humid conditions

Impact resistance: 500m/s ² (3 times in X/Y/Z directions), strong resistance to mechanical vibration

Voltage endurance: AC1000V 50/60Hz for 1 minute, excellent electrical insulation performance

Connection and Interface

Connection method: Two options are provided: wire lead out or provincial wiring connector

Attachment configuration: Standard user manual, simplified debugging process

Structural features: Black appearance, weight 9.98g, lightweight design for easy integration

Application advantages

High precision detection: Through the stability of the light source and digital display function, precise recognition of small objects is achieved

Anti interference design: When multiple devices work together, the signals do not interfere with each other, ensuring system reliability

Environmental tolerance: Wide temperature and humidity range and impact resistance, suitable for scenarios such as automotive manufacturing and electronic assembly
