KEYENCE LV-NH42 New and Original High quality

LV-NH42

The LV-NH42 model is a high-precision, long-distance area beam reflection digital laser sensor that uses visible red semiconductor laser (wavelength 660nm) as the light source and supports multi-level detection distances such as MEGA mode 1200mm, ULTRA mode 1000mm, SUPER mode 750mm, etc. It can adapt to the precise positioning needs of objects of different sizes in industrial automation scenarios. The product achieves high sensitivity detection through regional beam reflection technology. The outer shell is made of glass reinforced resin material, and the lens cover is made of multi aromatic compounds, with an IP67 protection level (some data shows a working temperature range of -10 ℃ to+55 ℃, humidity of 35% -85% RH without condensation). It weighs only about 65g and has a compact volume (some data mention a length of 6.8mm/width of 9.9mm). Its core functions include FDA (CDRH) Part 1040.10 Class 1 laser safety certification, wide power supply voltage (4.5-7V DC) input, fast response time (millisecond level), and anti-interference ability. It is widely used in industrial scenarios such as logistics sorting, precision machining, and automotive parts inspection that require long-distance non-contact measurement.

Technical specifcations for LV-NH42

Basic information

Model: LV-NH42

Type: Long distance area beam reflection digital laser sensor

Light source: Visible red semiconductor laser, wavelength 660nm

2、 Detection distance

MEGA mode: 1200mm

ULTRA mode: 1000mm

SUPER mode: 750mm

TURBO mode: 500mm

FINE mode: 250mm

HSP mode: 200mm

3、 Environmental adaptability

Environmental temperature: -10 ℃ to+55 ℃ (without freezing)

Relative humidity: 35% to 85% RH (non condensing)

4、 Material and Structure

Shell material: Glass reinforced resin

Lens cover material: polyaromatic compound

Weight: Approximately 65g

5、 Laser Safety and Certification

Laser classification: FDA (CDRH) Part 1040.10 Class 1, IEC 60825-1 Class 1 laser products

6、 Other characteristics

Protection level: IP67 (mentioned in some materials, specific may vary depending on product configuration or version)

Response time: Fast response, suitable for high-speed automated production lines

Anti interference capability: Possess good ability to resist environmental light interference, ensuring stable detection

Our Services:

1、All our products are new and orginal, and of good quality

2、Our prices are very competitive.

3、 We have a large quantity in stock, so we could help the customers to get the components which are dificult to get.

4、All inquiries will be valued and will reply in 24.

Packing & Delivery:

1、100% brand New and Original Factory Seal!

2、Warranty:1 year

3、Package: Original packing with cartons.

4、Delivery time: Shipped in 3-7 days after payment

5、All the goods will be tested before shipment
