KEYENCE PR-M51CP New and Original High quality

PR-M51CP

The PR-M51CP model is an ultra compact reflective photoelectric sensor that adopts an M8 connector type 4-pin interface design and supports free cutting of 1.2-meter standard cables to adapt to narrow space layouts. Its core detection module is equipped with a red LED point light source (650nm), which achieves a standard detection distance of 1.2 meters (with a minimum perception of 0.11mm level objects) through independent transmitters and receivers. The output terminal provides dual channel control function (ON when shading/ON when entering light), with a response time as low as 0.5ms, and the NPC/PNP dual-mode output is compatible with mainstream industrial control systems. The equipment has IP67 protection level and IP69K high-pressure flushing certification. The shell is made of SUS316L stainless steel and polysulfone material, which can operate stably in a temperature range of -25 ℃ to+55 ℃, 35% -85% RH humidity, and 1000m/s ² impact environment. It is particularly suitable for high-precision automation scenarios such as food packaging, logistics sorting, and 3C electronic assembly. In addition, this model integrates power reverse protection, output overcurrent protection, and surge absorption circuit, equipped with three color LED indicator lights (orange output indicator, green stable action indicator, green power indicator), in compliance with UL/CSA standards, supporting 7-day no reason return and quick stock supply service.

Technical specifcations for FU-57TZ

Basic specification parameters

Model and Type: PR-M51CP, a type of photoelectric sensor with an M8 connector 4-pin interface design, suitable for industrial automation detection scenarios.

Dimensions and weight:

Compact in appearance, with a length of about 10mm, a width of about 10mm, and a height of about 12mm (some data may vary slightly due to model subdivision).

The weight is about 26g, and the lightweight design is easy to install.

Shell material: SUS316L stainless steel shell is used, the indicator light shell and lens cover are made of polysulfone material, and the cable protection sleeve is made of polymethylpentene, which has high strength and corrosion resistance.

2、 Electrical performance parameters

Power supply voltage: Supports 10V to 30V DC wide voltage input, compatible with mainstream industrial power supply systems.

Output type: Supports NPC/PNP dual-mode output to meet different control system requirements.

Current consumption: transmitter current is about 11mA, receiver current is about 16mA, low-power design.

Control output:

The maximum output voltage is 30V DC and the maximum output current is 50mA.

Remaining voltage: ≤ 1.0V below 10mA, ≤ 1.5V between 10 and 30mA, ≤ 2.0V between 30 and 50mA.

Response time:

Output 1 (ON when blocked): 0.5ms.

Output 2 (ON when illuminated): 0.5ms (OFF → ON), 2.7ms (ON → OFF).

3、 Detecting performance parameters

Light source type: Red LED point light source (wavelength 650nm), 4-element point light source design, stable beam.

Detection distance: The standard detection distance is 1.2 meters, and the minimum detectable distance is 0.11mm, suitable for detecting small objects.

Optical axis diameter: The detection optical axis diameter is about 0.5mm, with high focusing accuracy.

Environmental lighting anti-interference:

Incandescent lamp environment: ≤ 5000lx.

Sunlight environment: ≤ 20000 lx.

4、 Environmental adaptability parameters

Protection level:

IP67 (IEC60529 standard), dustproof and waterproof.

IP69K (DIN40050-9 standard), resistant to high-pressure flushing.

Working temperature range: -25 ℃ to+55 ℃, no freezing environment.

Storage temperature range: -25 ℃ to+75 ℃.

Humidity range: 35% to 85% RH (non condensing).

Voltage endurance: 1000V AC, 50/60Hz, lasting for 1 minute.

Seismic resistance: 10Hz to 55Hz, double amplitude of 1.5mm, 2 hours in X/Y/Z direction.

Impact resistance: 1000m/s ², 6 times in X/Y/Z directions.

5、 Function and protection parameters

Output indicator light:

Orange: Output status indicator.

Green: Stable action indicator.

Green (transmitter): Power indicator light.

Protection circuit:

Reverse power protection.

Output overcurrent protection.

Power surge protection.

Insulation resistance: ≥ 20M Ω (500V DC).

6、 Installation and extension parameters

Connection method: M8 connector type 4-pin interface, supports 1.2-meter standard cable, can be freely cut to adapt to different installation requirements.

Control output number: Dual channel output, supporting two modes: ON when shading and ON when entering light.

Installation method: Supports flat bracket installation, suitable for compact device layout.
