FESTO VTUS-20-P-G14-GCU3-G18T-3A+H Manifold assembly
The FESTO VTUS-20-P-G14-GCU3-G18T-3A+H is a compact, modular manifold assembly designed forcentralized pneumatic control., lt integrates a 20-station valve base (VTUs-20-P) with G1/4" portconnections, a GcU3 electronic interface module for fieldbus communication (e.g. PROFINET, 1O-Link),and G1/8" pilot/exhaust ports (G18T). The 3A+H configuration includes three solenoid-operated 3/2-wayvalves (3A) and additional hydraulic/auxiliary ports (H) for expanded functionality. ldeal for automatedmachinery, this assembly streamlines pneumatic circuit design, reduces tubing complexity, and enablesflexible l/0 integration via its digital communication hub. Robust construction ensures reliability inindustrial environments.
Information：
Manufacturer Nr.: VTUS-20-P-G14-GCU3-G18T-3A+H
Manufacturer: Festo
Technical Data：
Electrical actuation：Individual connection
Electrical I/O system：no
Width dimension：22 mm
Operating medium：Compressed air as per ISO 8573-1:2010 [7:4:4]
Temperature of medium：-10 °C ... 50 °C
Ambient temperature：-10 °C ... 50 °C
Storage temperature：-20 °C ... 60 °C
Operating pressure：-0.09 MPa ... 1 MPa
Operating pressure：-0.9 bar ... 10 bar
Pilot pressure MPa：0.15 MPa ... 1 MPa
Pilot pressure：1.5 bar ... 10 bar
Operating pressure for valve manifold with internal pilot air supply：1.5 bar ... 10 bar
LABS (PWIS) conformity：VDMA24364-B1/B2-L
Cleanroom class：Class 6 according to ISO 14644-1
CE marking (see declaration of conformity)：as per EU explosion protection directive (ATEX)
UKCA marking (see declaration of conformity)：acc. to UK EX instructions
Certification：c UL us - Recognized (OL)
Sealing principle：Soft
Valve size：21 mm
Standard nominal flow rate：600 l/min ... 700 l/min
Exhaust air function：With flow control option
Pneumatic working port：G1/8
1/8 NPT
QS-4
QS-6
QS-8
QS-5/32
QS-1/4
QS-5/16
