UC-1/8 161419
Festo UC-1/8 (order number 161419) is a pneumatic muffler designed with plastic material, featuring a compact structure and lightweight characteristics (weighing only 2.6g). This model supports G1/8 external thread interface, with a working pressure range of 0 to 10 bar, suitable for compressed air systems (compliant with ISO8573-1:2010 standard), and can use lubricated or non lubricated compressed air. Its sound pressure level is 59 dB (A), the environmental temperature tolerance range is -10 ° C to 70 ° C, and the protection level reaches IP67, which meets RoHS environmental requirements. The product features include simple insertion and installation, high flow design, and multi thread selection, which can effectively reduce the exhaust noise of pneumatic systems, prevent pollution, and are widely used in the field of industrial automation.
Technical specifcations for UC-1/8 161419
model: UC-1/8
Order number: 161419
Type: Pneumatic Silencer
Interface and size
Pneumatic connection: G1/8 external thread
Container size: 1
Work pressure and medium
Working pressure range: 0 bar to 10 bar
Working medium: Compressed air (compliant with ISO8573-1:2010 standard)
Media description: Lubricated or non lubricated compressed air can be used
performance parameter
Sound pressure level: 59 dB (A)
Environmental temperature range:- 10 ° C to 70 ° C
Product weight: 2.6 g
Material and Protection
Threaded flange material: Polyethylene (PE)
Silencer plug-in material: Polyethylene (PE)
Compliant with RoHS environmental requirements
Features: Easy insertion and installation, compact design, high flow rate, multi thread selection
Application: Reduce exhaust noise of pneumatic systems, prevent pollution, suitable for industrial automation field
