Festo PUN-10X1,5-BL 159668 Plastic tubing
Description
FESTO PUN series is a highly flexible plastic tubing for use with compressed air, water and vacuum operating mediums. This air hose is manufactured from polyurethane which gives it flexibility suitable for use with energy chains and pneumatic applications with a high cycle rate.
Information
For easy transmission of compressed air in your pneumatic system, choose this robust hose from Festo. As it's made of polyurethane (PU) material, it's a durable and long-lasting choice that resists deformation. It's also flexible, with a minimum bending radius of 28mm so you can install it around corners without the risk of damage. The air hose comes as a single length of 50 metres and is easy to cut to size, making it suitable for multiple projects, both big and small.
- Highly flexible plastic tube
- Compatible with a wide variety of fittings
- Compressed air in accordance with ISO 8573¬1:2010
- Operating pressure: -0.95 to +10 bar
- Free of copper and PTFE
- Conforms to RoHS
- Wide operating temperature range of -35°C to +60°C for use in demanding industrial environments
- Light weight of 0.05kg/m for easy handling and minimal strain on your setup
- Blue colour for immediate identification as a pneumatic component
- Maximum operating pressure of 10 bar for heavy-duty applications
- Medical and dental equipment
- Industrial machinery
- Water-cooling systems
Technical Data
Outside diameter：10 mm
Bending radius relevant for flow rate：54 mm
Inside diameter：7 mm
Min. bending radius：28 mm
Application note：TPE-U Ester based
Application note：The plastic tubing may only be laid in contact with cables if their sheathing is free of phosphoric
Application note： acid esters. Otherwise the plastic tubing may get damaged.
Tubing characteristics：Suitable for energy chains
Operating pressure for entire temperature range：-0.095 MPa ... 0.7 MPa
Operating pressure for entire temperature range：-0.95 bar ... 7 bar
Operating pressure for entire temperature range：-13.775 psi ... 101.5 psi
Temperature-dependent operating pressure：-0.095 MPa ... 1 MPa
Temperature-dependent operating pressure：-0.95 bar ... 10 bar
Temperature-dependent operating pressure：-13.775 psi ... 145 psi
Certification：German Technical Control Board (TÜV)
Certificate issuing authority：B 013277 0506 00
Operating medium：Compressed air as per ISO 8573-1:2010 [7:-:-]
Material fire test：UL94 HB
LABS (PWIS) conformity：VDMA24364-B2-L
Ambient temperature：-35 °C ... 60 °C
Product weight by length：0.0489 kg/m
Pneumatic connection：For plug connection outside diameter 10 mm
Color：Blue
Shore hardness：D 52 +/-3
Note on materials：RoHS-compliant
Material of pneumatic tubing：TPE-U(PU)
