Festo HGWM-12-EO-G8 185701 Angle gripper Brand new

Festo HGWM-12-EO-G8 185701 Angle gripper

Description

Angular clamp HGWM-12-EO-G8 Micro, with tightening flange. Size 12, Maximum angular clearance ax, woes of jaws 0.5 deg, Maximum Sz clearance of jaws 0.03 mm, Maximum opening angle 18.5 deg, Repetition accuracy of grippers less than 0.02 mm

Information

Brand：FESTO

Manufacturer partnumber：185701

Series：HGWM

ERIKS item #：  11635244

Catalogue item no 1：185701

Technical Data

Size：12

Max. gripper jaw angular play ax, ay：0.5 deg

Max. gripper jaw backlash Sz：0.03 mm

Max. opening angle：18.5 deg

Pneumatic gripper repetition accuracy：≤ 0.02 mm

Type code：HGWM

Number of gripper jaws：2

Mode of operation：Single-acting Open

Gripper function：Angle

Design：Inclined plane

Position sensing：None

Symbol：00991897

Operating pressure：2 bar ... 8 bar

Max. operating frequency of pneumatic gripper：4 Hz

Min. opening time at 6 bar：3.7 ms

Min. closing time at 6 bar：1.8 ms

Operating medium：Compressed air as per ISO 8573-1:2010 [7:-:-]

Corrosion resistance class (CRC)：2 - Moderate corrosion stress

Ambient temperature：5 °C ... 60 °C

Spring return torque：0.013 Nm

Total gripping torque at 6 bar, closing：64 Ncm

Maximum force on gripper jaw Fz, static：20 N

Maximum torque on gripper jaw, Mx static：0.4 Nm

Maximum torque on gripper jaw, My static：0.4 Nm

Maximum torque on gripper jaw, Mz static：0.4 Nm

Product weight：45 g

Type of mounting：Clamped

Pneumatic connection：M3

Note on materials：Free of copper and PTFE

Cover cap material：POM

Housing material：High-alloy stainless steel

Gripper jaw material：High-alloy steel
