EMERSON CDAQ-9171 New and Original High quality

EMERSON CDAQ-9171 module

Item no.:
CDAQ-9171
Payment:
T/T
Market price:
$66
Price:
$99
Product origin:
US
Color:
New sealed
Lead Time:
In stock/1-3days

Inquiry now

product introduction

CDAQ-9171

The CDAQ-9171 model is a single slot USB bus powered CompactDAQ chassis designed specifically for small portable sensor measurement systems. This chassis enables quick connection between sensors and electrical measurement devices through a plug and play USB interface, without the need for additional power adapters, significantly simplifying the device deployment process. Its core functions include controlling the timing, synchronization, and data transmission between C-series I/O modules and external hosts. Users can flexibly combine analog I/O, digital I/O, and counter/timer modules to achieve synchronous acquisition and processing of multiple types of signals. The chassis is equipped with four 32-bit universal counters/timers, supporting orthogonal encoders PWM、 Application scenarios such as event counting, pulse sequence generation, and period/frequency measurement can be accessed through hardware timed digital C-series modules. This product, with its compact design, industrial grade reliability, and modular scalability, can adapt to various environments such as laboratories, production lines, and mobile testing platforms. It is particularly suitable for industrial automation and testing scenarios that require high synchronization measurement, providing users with flexible and efficient data acquisition solutions.

Technical specifcations for CDAQ-9171

Core functions and interfaces

Bus connector: adopts USB 2.0 interface, supports plug and play function, and can be quickly connected to PC, laptop or netbook through a single USB cable without the need for additional power adapters, simplifying the device deployment process.

Slot configuration: Equipped with one slot, it supports flexible configuration of C-series I/O modules. Users can combine analog I/O, digital I/O, and counter/timer modules according to testing requirements to achieve synchronous acquisition and processing of multiple types of signals.

2、 Counter and timer function

Built in counter: integrates 4 32-bit universal counters/timers, supports orthogonal encoders PWM、 Application scenarios such as event counting, pulse sequence generation, and period/frequency measurement.

Hardware timed access: Access counters through installed hardware timed digital C-series modules (such as NI 9401 or NI 9402) to ensure high-precision timing and synchronization performance.

3、 Environmental adaptability

Working temperature range: -20 ° C to 55 ° C, suitable for various environmental conditions such as industrial sites and laboratories.

Protection level: IP30 standard, with dust-proof ability, ensuring the stability of the equipment in harsh environments.

4、 Electrical and Mechanical Specifications

Input voltage range: Supports 10-30 VDC power supply, with a maximum power of 36W, meeting various power supply needs.

Size and weight: The product size is 223mm × 100mm × 259mm, with a weight of 2.4 kilograms. The compact design is easy to integrate and deploy.

5、 Software and Development Support

Drivers and Tools: NI DAQmx driver is standard, compatible with LabVIEW SignalExpress LE, LabVIEW, LabWindows/CVI, and Measurement Studio, providing DAQ assistant code generation function to simplify the development process.

Configuration tool: Integrated NI Measurement&Automation Explorer (MAX), supporting device configuration, testing, and sample program calling to improve development efficiency.

6、 Scalability and compatibility

Module compatibility: Supports over 50 dedicated measurement modules, suitable for thermocouples RTD、 Multiple sensors such as strain gauges, load and pressure sensors, torque components, accelerometers, flow meters, encoders, and microphones are used for measurement.

Multi tasking: It can simultaneously run 7 hardware timing operations from analog, digital, or counter/timer channels to meet complex testing requirements.
