NI-9203
NI-9203 is a high-performance 8-channel C-series current input module designed specifically for industrial control and monitoring systems. This module supports an input range of ± 20mA, with 16 bit resolution and a maximum sampling rate of 200kS/s, and can accurately capture dynamic signal changes. Its core advantage lies in the dual isolation barrier (250Vrms isolation) from the channel to the ground terminal, which achieves electrical isolation between the signal and the power supply through independent isolation circuits, effectively suppressing electromagnetic interference and ensuring system safety. The module adopts bolt terminal connection method, compatible with sealed coating version to adapt to humid or corrosive environment, providing reliable physical connection and protection. This product is widely compatible with CompactRIO embedded systems, R series expansion cases, and CompactDAQ platforms, supporting NI DAQmx drivers and LabVIEW development environments. It is suitable for industrial automation, process control, and scientific research testing scenarios, providing users with high-precision and high reliability current signal acquisition solutions.
Technical specifcations for NI-9203
Core electrical performance
Input range: Supports bidirectional current signal measurement from -20mA to 20mA, covering the typical output range of industrial sensors.
Resolution: High precision conversion is achieved using a 16 bit ADC, with a minimum distinguishable current change of approximately 0.61 μ A (within a 20mA range).
Sampling rate: The maximum sampling rate is 200kS/s, which meets the requirements of high-speed dynamic signal acquisition.
Isolation and protection characteristics
Channel isolation: Equipped with 250Vrms channel ground continuous isolation capability, certified by UL/IEC.
Transient suppression: Built in dual isolation barriers effectively resist electromagnetic interference in industrial sites.
Protection level: Overall IP30 protection, supports sealing coating option.
Mechanical and Connection Design
Module configuration: Single slot C-series compact structure, compatible with CompactRIO/CompactDAQ platforms.
Terminal type: equipped with bolt terminal connectors, supporting live plugging and unplugging.
Working temperature: Suitable for a wide temperature range of -20 ℃ to 55 ℃, with a vibration tolerance of 3g (5-500Hz).
Signal processing capability
Channel configuration: 8-channel single ended analog input, supporting differential mode expansion.
Anti aliasing filtering: Built in programmable digital filter with adjustable cutoff frequency.
Calibration accuracy: Full range error ≤ ± 0.05%, excellent long-term stability.
Certification and Compliance
Safety certification: certified by international standards such as UL 61010-1 and IEC 61010-1.
Electromagnetic compatibility: Complies with CISPR 11 Class A radiation standard, and meets the immunity requirements of IEC 61326.
Environmental compliance: RoHS/REACH directive compliant, halogen-free flame retardant material.
