Allen Bradley 2711-K3A10L1 Industrial Control System Brand new

Allen Bradley 2711-K3A10L1 Industrial Control System

The Allen-Bradley 2711-K3A10L1 is a Panelview 300 Standard Operator Terminal. This operator terminal is powered by an external 18-32V DC supply voltage and has a 3-inch display with embedded DeviceNet communication interface and RS232 Printer port. It has Eight (8) Function keys and a Keypad operator interface.

Technical specifications for 2711-K3A10L1

Backlight：100,000 hr LED backlight life

Brand：Allen-Bradley

Manufacturer：Rockwell Automation

Product Family：PanelView Standard Operator Terminals

Product Type：PanelView 300 Standard Operator Terminals

Display Type：Monochrome transflective LCD with LED backlight

Display Area：73 mm (w) x 42 mm (h) 2.87 in. (w) x 1.67 in. (h)

Resolution：128 x 64 Pixels

Keypad Assembly：8 function keys (F1…F8); Cursor keys; Numeric entry keys

Application memory：170 KB application runtime; 240 KB nonvolatile memory (application objects plus text and bitmaps)

Communication ports：DeviceNet; RS232 (Printer port)

Input Voltage range：18…32V DC (24V DC nom)

Enclosure：NEMA Type 12/13, 4X (Indoor use only), IP54, IP65

Status Indicators：COMM: Green Fault: Red

Part Number/Catalog No.：2711-K3A10L1

Product Line：Panelview 300

Display Size：3 in.

Display Color：Monochrome

Input Type：Keypad

Communication：DeviceNet Communication & RS-232 Port

Input Power：24 VDC

Memory：240 KB

Communication Cable：1761-CBL-PM02

Shipping Weight：3 lbs

Shipping Dimensions：11X8X6 in.

Series：A, B

Product Lifecycle Status*：Discontinued/Obsolete

Description:

The Allen-Bradley 2711-K3A10L1 is a PanelView 300 Terminal. The discontinued Allen-Bradley PanelView 300 2711-K3A10L1 is an operator terminal that enables the user to interface with their machine. The flat panel architecture of the 2711-K3A10L1 allows the user to maintain the high-level performance in a space-saving interface. Additionally, the display offers a variety of graphics on the monochrome display.

The 2711-K3A10L1 is part of the Allen-Bradley’s Bulletin 2711 PanelView Standard Operator Terminal. The 2711-L3A10L1 is specifically part of the PanelView 300 Monochrome terminal which is fitted with a Three (3) inches monochrome screen, Keypad assembly and a variety of communication port enabling the terminal to communicate, exchange data and perform monitoring and control with partner devices.

The 2711-K3A10L1 monochrome display has a Liquid Crystal Display (LCD) with integral LED backlight that is expected to operate up to 100,000 hour life when operated within specified operating parameters. The terminal’s effective display area is 73 mm (w) x 42 mm (h) or 2.87 in. (w) x 1.67 in. (h) with a resolution of 128 x 64 pixels.

The 2711-K3A10L1 comes with a integrated Flash Memory of 240K bytes intended for application screens as well as a variety of communication ports such as built-in RS232 printer port and a DeviceNet communication port.
