Allen Bradley 2711P-K4M20A PanelView Plus 400 Brand new

Allen Bradley 2711P-K4M20A PanelView Plus 400

The 2711P-K4M20A is a PanelView Plus Operator terminal. It is part of the Visualization product catalog that is manufactured by Allen-Bradley. It functions as a Human Machine Interface (HMI), featuring a Grayscale display measuring 3.8 inches with a resolution of 320 x 240 pixels. It comes with a Keypad operator interface; Ethernet and RS232 communication ports supporting Ethernet I/P, DH485, and DF1 protocols, respectively; USB ports for attachment of peripheral devices such as keyboard, mouse, and USB removable drive. This terminal operates at an input supply voltage of 85-264 VAC, 47-63 Hz.

Technical specifications for 2711P-K4M20A

Manufacturer：Rockwell Automation

Part Number/Catalog No.：2711P-K4M20A

Display Size：3.8 Inch

Brand：Allen-Bradley

Product Family：PanelView Plus Compact Terminals

Product Type：Operator Terminals

Product Category：PanelView Plus 1000

Input lifespan：1 million actuations

Display Type：Grayscale passive matrix, film compensated super-twist nematic (FSTN) Color active matrix, thin-film tra

Backlight：CCFL, 50,000 hours min at 25 ° C (77 °F), non-replaceable

Display Area：77 x 58 mm (3.0 x 2.3 in.)

Resolution：320 x 240

Internal memory：5MB / 10 MB Flash Memory

Logic Module: None

Integrated ports：Ethernet, RS-232, 1 USB host

Input Voltage range：85-264VAC, 47-63 Hz

Manufacturer：Rockwell Automation

Product Line：Panelview Plus 400

Brand：Allen-Bradley

Product Family：PanelView Plus Terminals

Display Color：Grayscale

Product Type：Operator Terminals

Input Type：Keypad

Part Number：2711P-K4M20A

Communication：Ehternet and RS-232 Ports

Input Type：Keypad

Input Power：AC

No. of Function keys：Eight (8) F1-F8

Real Time Clock (RTC)：Battery-backed clock

Memory：64 MB

Clock accuracy：+/-2 minutes per month

Series：A, B, C, D, E

Display Area：77 x 58 mm (3.0 x 2.3 in.)

Resolution：320 x 240 pixels

Application memory：5 MB for series A; 10 MB for Series B

Product Lifecycle Status*：Discontinued/Obsolete

Communication ports：Ethernet; RS232; USB

Communication protocols：TCP I/P; DF1; DH485

Input Voltage range：85-264 VAC, 47-63 Hz

Description:

The 2771P-K4M20A is a Human Machine Interface (HMI) device that is part of Allen-Bradley’s Visualization components. This device is designed for use in a wide variety of applications, enabling real-time monitoring and control of machines or processes. It is typically paired with a Programmable Logic Controller (PLC), Programmable Automation Controller (PAC), especially compatible with Allen-Bradley products however, may also be used with 3rd party controllers. The 2771P-K4M20A has a 3.5-inch grayscale display with a resolution of 320 x 240 pixels and a viewing area of 77 x 58 mm (3.0 x 2.3 in.). The available operator interface to this HMI is an assembly of keypad buttons that is comprised of function keys, navigation, numeric, and confirmation buttons. Only the functions keys of the 2771P-K4M20A are fully-programmable and may accept varying assignments in reference to the active window for operational flexibility.

The 2771P-K4M20A is an Allen-Bradley Human Machine Interface (HMI) that is primarily used to implement real-time process visualization and control of a connected machine or industrial application. This operator terminal allows operators and plant personnel to monitor and control the process from a convenient, central location on the factory floor. This HMI device simplifies operation, contributes to overall accuracy and efficiency, and reduces safety risks. The 2711P-K4M20A is part of the PanelView Plus operator terminal. Specifically, it is part of the PanelView Plus 400 operator terminal. It has a 3.5-inch grayscale display, with a display area of 77 x 58 millimeters (3.0 x 2.3 inches) and a resolution of 320 x 240 pixels. The available input interface to this operator terminal is an assembly of keypads that is composed of numeric and navigation keys as well as function keys that can be assigned with global and local functions.
