MGPM20TF-30Z
The MGPM20TF-30Z model product is a thin cylinder with a guide rod, belonging to the MGP-Z series. It adopts a compact design and the built-in guide rod structure can effectively prevent the piston rod from rotating, significantly improving load stability and guidance accuracy, especially suitable for high-precision positioning scenarios. Its cylinder diameter is 20mm, stroke is 30mm, and the main material is aluminum alloy, which combines lightweight and high-strength characteristics to meet the requirements of compact space layout. This product supports a dual acting drive mode, achieving bidirectional linear motion of the piston through compressed air. It has a maximum pressure resistance of 1.0 MPa and a working temperature range of -10 ℃ to 60 ℃. It is compatible with air as the driving medium and does not require additional lubrication, making maintenance convenient. In addition, its guide rod has been shortened by 22mm, and the optimized design of the front end plate thickness has reduced the weight by 24%, significantly reducing the amount of installation avoidance processing. It is also compatible with circular magnetic switches and strong magnetic switches, and can be installed directly without partitions, further improving space utilization and system integration. It is widely used in industrial fields such as electronic manufacturing and precision assembly, which require strict requirements for equipment miniaturization and motion accuracy.
Technical specifcations for MGPM20TF-30Z
Infrastructure parameters
Model: MGPM20TF-30Z
Series: MGP-Z series with guide rod thin cylinder
Cylinder diameter: 20mm
Journey: 30mm
Main material: aluminum alloy, combining lightweight and high-strength characteristics, suitable for compact space layout requirements.
Guide rod structure: Built in guide rod can effectively prevent the piston rod from rotating, improve load stability and guidance accuracy, especially suitable for high-precision positioning scenarios.
Bearing type: sliding bearing, providing lateral stability and protecting the cylinder from lateral load impact.
Installation method: Basic installation, easy to fix on the surface of the equipment or integrate into modular valve groups.
2、 Performance parameters
Action mode: Single rod double action, achieving bidirectional linear motion of the piston through compressed air.
Work pressure range:
Minimum operating pressure: 0.1 MPa
Maximum operating pressure: 1.0 MPa
Guaranteed pressure resistance: 1.5 MPa
Working temperature range: -10 ℃ to 60 ℃, can adapt to temperature changes in conventional industrial environments.
Using fluid: air, no additional lubrication required, simplifying maintenance process.
Buffer form: cushion cushion, reduce piston rod impact noise, and extend cylinder service life.
Piston speed range: 50-500mm/s, supporting high-speed or low-speed working conditions, suitable for different motion rhythm requirements.
Non rotational accuracy: ± 0.07 °, ensuring high-precision positioning.
3、 Interface and installation parameters
Pipe diameter (air pressure port): 1/8 inch, compatible with standard pneumatic pipeline interfaces.
Type of through-hole thread: Rc thread, easy to connect with joints or valve groups.
Magnetic switch compatibility: Built in magnetic ring, supports magnetic switch installation (requires additional configuration), facilitates position detection function.
Installation method of magnetic switch: Circular magnetic switch and strong magnetic field resistant magnetic switch do not require partitions and can be directly installed, further improving space utilization and system integration.
4、 Size and weight optimization
Shortening of guide rod: up to 22mm, reducing the amount of machining for clearance holes during cylinder installation and saving space.
Front end board thickness change: weight reduction of up to 24%, further reducing equipment load.
