Lenze ESMD251X2SFA I5DAE175F10V10000S i550 IP20 0.75kW 400V 3ph AC Inverter Drive Brand new

Lenze I5DAE175F10V10000S i550 IP20 0.75kW 400V 3ph AC Inverter Drive

Description

Lenze i550 Series AC Inverter for 0.75kW (1HP) 400V 3 Ph motor to 2.4A. Converts fixed frequency three phase 400V input to variable frequency three phase 400V to control the speed of a standard AC Induction motor. Operates in standard VxFor Sensorless Vector Control.

Technical Data

Output rating to 2.4A

Overload: 150% x 60 seconds; 200% x 3 seconds.

Size A: 60mm Wide x 130mm Deep x 214 mm High. IP20.

Weight: 1kg.

Speed Control Range: 0-599Hz

Braking: Internal Brake Switch fitted for use with External Brake Resistor (not supplied)

Braking Switch Limits: Min Resistance: 390 Ohms, Max Brake Current: 2 A. See Linked Products below for resistor or use the ‘Which Resistor’ button on this page.

No operator keypad included; see linked products below.

2 x Analogue Inputs, 5 x Digital Inputs, 1 x Analogue Output, 1 x Digital Output (Open Collector not Volt Free), 1 x Volt Free Change Over Contact (240V, 3A Max), dedicated PTC Input (Linked as default)

An extended I/O module is available - see linked products below

No communications included. Control modules with comms are available – see linked products below.

Fitted with coated PCB's as standard

Input Choke: Optional; Input Current shown without Line Reactor

Input Current: 3.3A

Input Voltage: 380-480V Three Phase +10% -15% at 50-60Hz ±5%

EMC Compliance: IEC 61800-3 Second Environment C2 (Industrial). Filter can be disconnected (Remove IT Screws)​

Cubicle mount.

Rated 45°C Ambient.

Ventilation space above and below: 50mm, at sides: 0mm, in front: [not specified].

Heat Loss at max output: 32W.

Mounting via 2 x 5mm diameter holes at rear on 190mm centres (Not DIN Mountable).
