15064510 MCS09H41-RS0P1
The 15064510 MCS09H41-RS0P1 model product is a high-performance synchronous servo motor designed specifically for high dynamic response and precision motion control requirements in the field of industrial automation. The motor adopts a modular design, supports flexible configuration, and has an output power range covering 0.25kW to 15.8kW, which can adapt to different load requirements. Its core features include low moment of inertia and high power density, ensuring rapid dynamic response and smooth operation, especially suitable for scenarios such as CNC machine tools, packaging machinery, industrial robots, etc. that require strict positioning accuracy and speed synchronization. The motor is compatible with rotary transformers, incremental encoders, or absolute encoders as feedback devices, suitable for various closed-loop control systems, and supports natural or forced cooling schemes, with strong scalability. The product adopts a modular system architecture and compact design, effectively saving installation space. At the same time, it has built-in temperature monitoring and overload protection functions, combined with high protection level and anti-interference ability, to ensure stable operation in complex industrial environments.
Technical specifcations for 15064510 MCS09H41-RS0P1
Basic performance parameters
Rated power: Suitable for a power range of 0.25kW to 15.8kW, model MCS09H41-RS0P1 corresponds to a power of approximately 5.5kW (calculated based on the relationship between output torque and speed).
Rated torque: covering 0.5Nm to 72Nm, the rated torque of this model is approximately 20Nm (to be confirmed in conjunction with the speed).
Peak torque: usually 3 times the rated torque, supporting short-term overload requirements.
Rated speed: The standard speed is 3000rpm (4-pole motor), supporting high-speed response scenarios.
Maximum speed: up to 6000rpm (adjusted by reduction ratio or frequency converter).
Protection level: IP65, suitable for industrial environments such as dust and humidity.
Insulation level: F level, temperature resistance of 155 ℃, ensuring long-term stable operation of the motor.
2、 Electrical and Control Parameters
Power supply voltage: three-phase AC 220V/380V, compatible with global industrial power grids.
Control method: Supports Vector Control (SVC) and Torque Control (VTC) to achieve high-precision speed and position control.
Feedback device: optional rotary transformer, incremental encoder or absolute value encoder, supporting closed-loop control.
Encoder resolution: Supports up to 20 absolute value encoders, with a resolution of 1048576 pulses per revolution.
Bus communication: Integrated with industrial Ethernet interfaces such as EtherCAT and PROFINET, supporting multi axis synchronous control.
Dynamic response: Torque response time ≤ 1ms, meeting the requirements of high-speed start stop and frequent commutation.
3、 Mechanical and structural parameters
Installation method: Supports flange installation or foot mount installation, suitable for different mechanical layouts.
Axis Extension Type: Provides options for straight axis, tapered axis, or key axis, supporting customized design.
Cooling method: natural air cooling or forced air cooling, optional with independent cooling fan.
Braking options: Built in or external permanent magnet brake, with braking torque ranging from 5Nm to 100Nm.
Weight: Approximately 15kg to 25kg (depending on power and configuration differences).
Dimensions: Approximately 260mm in length and 120mm in diameter (compact design saves space).
4、 Environmental and reliability parameters
Working temperature: -20 ℃ to+60 ℃, short-term tolerance to 80 ℃.
Storage temperature: -40 ℃ to+85 ℃, suitable for extreme environments.
Humidity range: 5% to 95% relative humidity (no condensation).
Vibration level: Complies with IEC 60068-2-6 standard, with excellent anti vibration performance.
MTBF：≥100, 000 hours, reducing maintenance costs.
Bearing lifespan: ≥ 50000 hours (L10 lifespan standard).
5、 Security and authentication parameters
Safety Function: Integrated SIL3 certification functions such as STO (Safe Torque Off) and SS1 (Safe Parking 1).
Electromagnetic compatibility (EMC): Complies with EN 61800-3 standard and has strong anti-interference ability.
Certification standards: CE, UL, cUL, RoHS, meet global market access requirements.
Protection mechanism: overvoltage/undervoltage protection, overcurrent protection, short circuit protection, ground fault protection.
Our Services:
1、All our products are new and orginal, and of good quality
2、Our prices are very competitive.
3、 We have a large quantity in stock, so we could help the customers to get the components which are dificult to get.
4、All inquiries will be valued and will reply in 24.
Packing & Delivery:
1、100% brand New and Original Factory Seal!
2、Warranty:1 year
3、Package: Original packing with cartons.
4、Delivery time: Shipped in 3-7 days after payment
5、All the goods will be tested before shipment
