Keyence has announced the launch of its latest-generation instant measurement system, the IM-X1000 series. This modular system is specifically designed to meet the demands of modern inspection requirements. With just a single button press, the IM-X series can measure up to 5,000 dimensions in a mere second. Moreover, it comes equipped with a brand-new ultra-wide platform, multi-sensor measurement capabilities, and a globally pioneering automation feature that enables the programming of complex and time-consuming parts.

Modular Design to Meet Diverse Inspection Needs

The core advantage of the system remains its ability to significantly shorten inspection times through fast, easy, and accurate measurements. However, it now boasts even more powerful functions. The IM-X supports up to 20 different platform and camera combinations, allowing for the construction of measurement systems tailored to specific tasks. Ranging from general-purpose optical comparator applications to advanced multi-sensor configurations, the IM-X offers flexible solutions to meet a wide variety of inspection needs.

Expanded Measurement Range for Larger Components

Thanks to the expansion of the system's measurement range, large parts can now be easily measured. The measurement range reaches up to 406 mm x 508 mm (16 inches x 20 inches), which is 3.3 times that of previous generations. This all-in-one system accommodates parts of various sizes and is equipped with a rich set of measurement tools, helping to streamline the quality control process.

Multi-Sensor Functionality for Comprehensive Inspection

The IM-X integrates optical, contact probe, laser, and rotary measurement technologies, enabling truly comprehensive part inspection within a single system. This multi-sensor approach allows manufacturers to collect a broader range of dimensional data without the need for multiple standalone instruments.

Revolutionizing Programming with Intelligent Automation

Programming has also been innovated to further enhance efficiency, with the ability to import drawings and automatically create programs. By importing CAD, PDF, JPEG, or even paper drawings, users can generate inspection programs simply by selecting key dimensions, design values, and tolerances. The IM-X also features an AI-driven programming tool, Smart Assist, which automatically adjusts focus, lighting, and edge extraction settings. This eliminates guesswork and reduces the need for manual adjustments, providing expert-level programming and optimal performance even for users with no prior experience in optical metrology.

With the IM-X series, manufacturers can conduct a comprehensive inspection of parts with just a single button press. This saves time, ensures product quality, reduces scrap and rework, eliminates bottlenecks, and enables continuous improvement in the production environment.
