KEYENCE OP-88680 New and Original High quality

OP-88680

The OP-88680 model product is a high compatibility control cable assembly designed specifically for industrial grade barcode readers and visual sensors. It adopts a compact 2.1mm × 2.3mm × 1.1mm wire structure, supports a standard wire length configuration of 10 meters, and is compatible with Keyence SR-X series laser scanners (such as SR-700/SR-X100W) and IV series image sensors (such as IV-HG500CA/IV-HG600MA). It is compatible with M12-A encoding interface and C interface direct connection scheme. Its core electrical parameters cover a wide range of 2.5V to 7.5V power input, supports extreme temperature operation from -50 ° C to+125 ° C, and has passed RoHS certification. The cable uses double-layer aluminum foil and tin plated copper braided shielding layer, with electromagnetic interference attenuation. ≥ 65dB (10MHz-1GHz), capable of withstanding strong electromagnetic noise generated by industrial field frequency converters, motors, and other equipment. The sheath material of this model is oil resistant polyurethane, with a protection level of IP69K, which can withstand high-pressure water gun flushing and oil pollution erosion. It is suitable for scenarios such as welding seam tracking in automotive welding workshops and dynamic QR code reading of electronic components. Its tensile strength is ≥ 100N, and it has passed 150000 dynamic bending tests. It supports a rotating locking nut design with 360 ° free angle adjustment. The cable surface integrates anti misplacement identification and color ring coding system, compatible with OP-87899 series polarizer accessories and IV-GD10 circular lighting module plug and play extension, with a signal transmission accuracy of ± 0.1mm, ensuring data integrity in high-frequency vibration environments of CNC machine tools or robot arms.

Technical specifcations for OP-88680

Interface and Connection:

Interface type: Supports direct connection between M12-A encoding interface and C interface, compatible with Keyence SR-X series laser scanners (such as SR-700/SR-X100W) and IV series image sensors (such as IV-HG500CA/IV-HG600MA), achieving plug and play functionality.

Connection method: Adopting a compact interface design, it is easy to install and debug quickly, and adapts to the complex wiring requirements of industrial sites.

Electrical performance:

Power supply voltage range: Supports wide range power input from 2.5V to 7.5V, compatible with the power supply needs of different industrial equipment, ensuring stable operation even in voltage fluctuation environments.

Signal accuracy: Through customized line sequence matching, high-precision signal transmission at the ± 0.1mm level is achieved, meeting the strict requirements of industrial visual inspection systems for data accuracy.

Environmental adaptability:

Working temperature range: Supports an extreme temperature range of -50 ° C to+125 ° C, and can operate stably under extreme temperature conditions such as high cold or high-temperature workshops.

Protection level: reaching IP69K standard, it can completely prevent dust from entering and withstand high-pressure water gun flushing and oil pollution erosion. It is suitable for industrial environments with high dust, humidity or requiring regular flushing.

Electromagnetic compatibility:

Shielding effectiveness: Built in double-layer aluminum foil+tinned copper braided shielding layer, electromagnetic interference attenuation ≥ 65dB (in the frequency range of 10MHz to 1GHz), effectively resisting strong electromagnetic noise generated by industrial field frequency converters, motors and other equipment.

Mechanical properties:

Tensile strength: Built in stress relief structure, tensile strength ≥ 100N, preventing cable breakage during frequent movement or pulling.

Bending resistance: Through 150000 dynamic bending tests, it ensures long-term reliability in complex wiring scenarios.

Cable specifications:

Cable length: The standard cable length is 10 meters, suitable for long-distance signal transmission needs.

Cable size: The outer diameter of the cable is 2.1mm x 2.3mm x 1.1mm (length x width x height), adopting a compact design for easy wiring in narrow spaces.

Installation and maintenance:

Interface design: Integrated rotatable locking nut, supporting 360 ° free angle adjustment, easy to install and debug quickly.

Identification system: The cable surface is printed with anti misplacement identification and color ring coding system, which facilitates quick identification and maintenance, reducing human operation errors.

Scalability and compatibility:

Attachment support: Supports plug and play extension with OP-87899 series polarizer accessories and IV-GD10 circular lighting module to meet the needs of special detection scenarios.

Device compatibility: Compatible with multiple visual inspection devices from Keyence, ensuring flexibility and convenience in system integration.

Our Services:

1、All our products are new and orginal, and of good quality

2、Our prices are very competitive.

3、 We have a large quantity in stock, so we could help the customers to get the components which are dificult to get.

4、All inquiries will be valued and will reply in 24.

Packing & Delivery:

1、100% brand New and Original Factory Seal!

2、Warranty:1 year

3、Package: Original packing with cartons.

4、Delivery time: Shipped in 3-7 days after payment

5、All the goods will be tested before shipment
