KEYENCE LV-S71 New and Original High quality

LV-S71

The LV-S71 model product is an ultra small digital laser sensor that uses a visible red semiconductor laser (wavelength 655nm) with a 1.2mm ultra small light spot diameter and a 500mm long-distance detection capability. It is suitable for rapid design and installation of production lines in industries such as environmental protection, chemical engineering, electronics, and batteries. This product complies with the Class 1 laser product specifications of FDA (CDRH) Part 1040.10 and IEC 60825-1 standards, with an ambient temperature tolerance range of -10 to+50 ° C (no freezing). The housing is made of stainless steel and polyaromatic compound materials, and the lens cover is made of norbornene plastic, weighing approximately 70g. It combines high precision, environmental resistance, and compact design, making it an ideal choice for industrial automation testing.

Technical specifcations for LV-S71

Model and type

model: LV-S71

Type: Small standard laser sensor

Laser classification: FDA (CDRH) Part 1040.10 Class 1 laser products, IEC 60825-1 Class 1 laser products

Light source and wavelength

Light source: Visible red semiconductor laser

Wavelength: 655 nm

detection distance

MEGA mode: 500 mm

Environmental resistance

Environmental temperature: -10 to+50 ° C (without freezing)

Material and Structure

Shell: The metal parts are made of stainless steel, and the plastic parts are made of polyaromatic compounds

Lens cover: The transmitter is made of norbornene plastic, and the receiver is made of polyaromatic compounds

weight

About 70 grams

Working voltage and output mode

Working voltage: 220V (some information mentioned, need to be confirmed according to specific applications)

Output mode: NPN/PNP (configurable according to application requirements)

Protection level and standards

Protection level: Complies with industrial environment usage standards

Standard: IEC 60825-1, FDA (CDRH) related laser safety standards

Application and Characteristics

Features: Ultra small size, output indicator light, spot diameter of 1.2mm, detection spacing of 0.5mm (compared with LV-S72)

Application: Suitable for rapid design and installation in industrial automation production lines

Our Services:

1、All our products are new and orginal, and of good quality

2、Our prices are very competitive.

3、 We have a large quantity in stock, so we could help the customers to get the components which are dificult to get.

4、All inquiries will be valued and will reply in 24.

Packing & Delivery:

1、100% brand New and Original Factory Seal!

2、Warranty:1 year

3、Package: Original packing with cartons.

4、Delivery time: Shipped in 3-7 days after payment

5、All the goods will be tested before shipment
