KEYENCE LV-N11CP New and Original High quality

LV-N11CP

The LV-N11CP model product is a high-precision digital laser sensor amplifier unit that uses laser as the detection light source. It has one PNP output and supports a wide temperature working environment from a minimum of -50 ° C to a maximum of 100 ° C. The power supply voltage range is 2V to 8V (RoHS certified). Its core functions include LIGHT-ON/DARK-ON mode switching, timer function (supporting 1ms to 9999ms delay), response time ranging from 80 µ s (high-speed) to 16ms (ultra long) with six selectable levels, maximum output current of 100mA, polarity reversal protection, overcurrent protection, and surge absorption function. This product expands the main device through an M8 connector and can connect up to 17 devices (2 outputs count as 2 devices). The housing is made of polycarbonate material, with dimensions of 32.6mm (H) × 9.8mm (W) × 78.7mm (L) and a weight of approximately 20g. It is widely used in industrial automation testing scenarios.

Technical specifcations for LV-N11CP

Model and type

model: LV-N11CP

Type: 1-channel output, PNP type digital laser sensor amplifier

CONNECTIVITY and EXPANSION

Connector: M8 connector

Scalability: Up to 17 devices can be connected (2 output types are considered as 2 devices)

Output and Control

Output: 1 PNP collector open circuit output

Output current: maximum 100 mA (independent); Two outputs totaling 100 mA (when multiple connections are made, one output can reach a maximum of 20 mA)

Output voltage: residual voltage of 1.2 V or lower (10 mA or less) at 30 V; 2.2 V or lower (10 to 100 mA)

t PI DAR

Timer type: Off/Off delay timer/On delay timer/Single timer

Duration: 1 ms to 9999 ms, maximum error ± 10%

response time

Options: 80 µ s (High Speed)/250 µ s (Fine)/500 µ s (Turbo)/1 ms (Super)/4 ms (Ultra High Speed)/16 ms (Ultra Long)

Power supply and power consumption

Power supply voltage: 24 VDC (operating voltage 10-30 VDC, including ripple)

Ripple: P-P below 10%, Class 2 or LPS

Power consumption: Normal 950 mW or less (at 30 V), Eco mode minimum 650 mW or less

Environmental resistance

Environmental temperature: -20 to+55 ° C (no freezing)

Relative humidity: 35 to 85% RH (non condensing)

Seismic resistance: 10 to 55 Hz, double amplitude of 1.5 mm, 2 hours each in the X, Y, and Z directions

Impact resistance: 500 m/s ², 3 times in X, Y, Z directions each

physical property

Shell material: polycarbonate

Dimensions: H 32.6 mm × W 9.8 mm × L 78.7 mm

Weight: Approximately 20 grams

Protection circuit

Polarity reversal protection, overcurrent protection, surge absorber

other characteristics

Input time: External input 2 ms (ON)/20 ms (OFF) or longer

Number of anti-interference devices: Depending on the type of connected equipment (0 to 4)

This product is suitable for industrial automation detection scenarios, achieving high-precision detection through laser light sources. It has multiple protection functions and environmental adaptability, meeting the needs of complex industrial environments.
