KEYENCE GT2-H12L Sensor Head
Description
Manufacturer : Keyence
Product No. : GT2-H12L
Product type : Low Measuring Force Type
Detection system : Scale Shot System, absolute (no tracking errors) type
Measuring range : 12 mm 0.47"
Operation indicator : 2-color LED (red, green)
Ambient temperature : -10 to +55°C 14 to 131°F (No freezing)
Relative humidity : 35 to 85% RH (No condensation)
Main body : Main body case: die-cast zinc, Indicator: polyarylate (PAR)
Sensor head cable : Optional (connect to the M8 connector)
Shipping Weight : 3 K
Technical Data
Description: Sensor Head
Weight: Approx 95 g (excluding cable)
Footnotes: *1 Value when the ambient temperature is 20°C 68°F. *2 Value at center of measuring range. Please note that the measurement force changes depending on the installation state of the dust boots. *3 The contact is included with the sensor.
Resolution: 0.5 ?m 0.02 Mil
Detection system: Quartz glass scale, CMOS image sensor projection system, Absolute type (without tracking error)
Measuring range: 12 mm 0.47"
Indicated accuracy: 2 ?m 0.08 Mil (p-p)*1
Measuring force - Downward mounting: 0.4 N*2
Measuring force - Side mounting: 0.3 N*2
Measuring force - Upward mounting: 0.2 N*2
Mechanical response: 4 Hz*1
Operation indicator light: 2-color LED (red, green)
Environmental resistance - Ambient temperature: -10 to +55°C 14 to 131°F (No freezing)
Environmental resistance - Relative humidity: 35 to 85% RH (No condensation)
Environmental resistance - Vibration: 10 to 55 Hz, 1.5 mm 0.06", double amplitude, 2 hours in each of X, Y, and Z directions
Materials - Main body: Main body cast: Zinc die-casting, Indicator: Polyarylate
Materials - Dust boot: -
Materials - Contact: TYPE304, 440C Stainless steel*3
Sensor head cable: Optional (connect to the M8 connector)
Our Services:
1、All our products are new and original, and of good quality.
2、Our prices are very competitive.
3、We have a large quantity in stock, so we could help the customers to get the components which are difficult to get.
4、All inquiries will be valued and will reply in 24.
Packing & Delivery:
1)100% brand New and Original Factory Seal!
2)Warranty: 1 year
3)Package: Original packing with cartons.
4)Delivery time: Shipped in 3-7 days after payment
5) All the goods will be tested before shipment.
