GT2-H12KF

GT2-H12KF is a high-precision contact type digital sensor based on an absolute scale pulse system. It adopts a flange installation structure and a quartz glass grating scale, combined with a CMOS image sensor to achieve a resolution of 0.1 μ m and a full range accuracy of ± 1 μ m (p-p). Its 12mm measurement range is compatible with three installation methods: downward/horizontal/upward, corresponding to measurement forces of 1.0N 0.9N and 0.8N, the sensor head adopts a zinc die-casting body and an IP67 protective structure, which can work continuously in an environment temperature of -10 ° C to+55 ° C, and has a 10Hz mechanical response and a 1ms sampling period. It can be quickly connected to an amplifier through an M8 connector and supports multi head parallel connection (up to 5 sensor heads can be connected to one amplifier). It is suitable for semiconductor wafer positioning, precision mold detection, and 3C electronic component assembly scenarios. Its built-in dual color LED indicator light can display the operating status in real time, and has passed 1000m/s ² impact resistance test and 10-55Hz three-axis anti vibration test, ensuring reliability in harsh industrial environments.

Technical specifcations for GT2-H12KF

Core detection performance

Detection system: Adopting an absolute scale pulse system, based on quartz glass grating scale and CMOS image sensor technology, it can achieve non-contact high-precision measurement without generating tracking errors.

Measurement range: 12mm, suitable for precision detection needs at medium to short distances.

Resolution: 0.1 μ m, capable of capturing small size changes.

Accuracy: ± 1 μ m (p-p), providing high repeatability and accuracy within the measurement range.

Sampling period: 1ms, meeting the requirements of high-speed dynamic measurement.

Mechanical response: 10Hz, can quickly respond to displacement changes of the measured object.

2、 Physical and installation characteristics

Installation method: Supports three installation directions: downward, horizontal, and upward, with measurement forces of 1.0N, 0.9N, and 0.8N respectively, which can adapt to different working conditions.

Main material: Made of zinc die-casting, it has high strength and durability.

Protection level: IP67, compliant with IEC standards, effectively dustproof and waterproof, suitable for harsh industrial environments.

Indicator light: equipped with dual color LED (red, green), real-time display of operating status, convenient for operators to monitor equipment status.

3、 Environmental adaptability

Working temperature range: -10 ° C to+55 ° C (without freezing), capable of stable operation in extreme temperature environments.

Relative humidity range: 35% to 85% RH (non condensing), suitable for high humidity environments.

Seismic resistance: Tested for 2 hours on each of the X, Y, and Z axes with a frequency range of 10 to 55Hz and a double amplitude of 1.5mm to ensure measurement accuracy even in vibration environments.

Impact resistance: Complies with IEC60068-2-27 standard, can withstand an impact of 1000m/s ², and has high resistance to mechanical damage.

4、 Electrical and Interface

Working power supply voltage: 24VDC, compatible with industrial power standards.

Connection method: M8 connector is used, supporting fast and reliable electrical connection.

Multi head parallel capability: A single amplifier can connect up to 5 sensor heads, facilitating system expansion and integration.

5、 Materials and Structure

Indicator light material: made of polyaromatic compounds (PAR), with high strength and weather resistance.

Dust cover material: Made of NBR rubber, it can effectively prevent dust and liquid from entering.

Contact material: SUS304 and SUS440C stainless steel are used, which have high strength and corrosion resistance.
