KEYENCE FU-57TZ New and Original High quality

FU-57TZ

The FU-57TZ model fiber optic sensor is an ultra compact, high-precision industrial grade detection equipment that adopts a side light output design and a 1-meter free cutting fiber unit, which can adapt to the installation needs of narrow spaces. Its core detection capability achieves micrometer level accuracy, and can recognize small objects as small as ø 0.005mm. It achieves high contrast detection through a focused spot with an optical axis diameter of ø 0.5mm, making it particularly suitable for precise identification of low reflectivity workpieces in electronic components, precision machining, and semiconductor manufacturing scenarios. The device adopts a fully sealed structure and IP67 protection level, which can operate stably in extreme temperatures ranging from -40 ℃ to+50 ℃, as well as in humid and dusty environments. It supports standard/high-power dual-mode switching, and with saturation exemption function, it can effectively eliminate environmental light interference and ensure long-term detection stability. In addition, its ultra high definition multilingual display screen supports interface switching between Chinese and English, with an intuitive and easy-to-use operation interface and a response time of only a few milliseconds. When combined with the FS-V30 series amplifier, it can achieve efficient integration from signal acquisition to data output, and is widely used in automation scenarios such as automotive parts assembly lines, pharmaceutical packaging foreign object detection, and 3C product defect screening.

Technical specifcations for FU-57TZ

Core detection parameters

Optical axis and detection capability

Optical axis diameter: When detecting standard objects, the optical axis diameter is ø 0.5mm to ensure beam focusing accuracy.

Minimum detectable object: Able to recognize small objects up to 0.005mm in diameter, suitable for high-precision detection scenarios.

Light emission direction: Side light emission design, suitable for installation needs in narrow spaces.

Fiber optic device parameters

Fiber length: 1 meter free cutting, supports customized length.

Fiber diameter: ø 1.0mm, balancing flexibility and transmission stability.

Minimum bending radius: R2mm (without bending) to avoid attenuation of fiber optic signals.

2、 Electrical performance parameters

Power supply voltage: compatible with 6-36V DC wide voltage input, suitable for different industrial power supply environments.

Output type: Supports NPN/PNP output and is compatible with mainstream control systems.

Response frequency: 1Hz, meeting low-speed detection requirements.

Sensitivity and repeatability: The sensitivity is adjustable, the repeatability accuracy is high, and the consistency of detection is ensured.

3、 Environmental adaptability parameters

Working temperature: -40 ℃ to+50 ℃, stable operation under extreme temperatures.

Protection level: Fully sealed structure, protection level not explicitly marked as IP67 but possessing similar environmental resistance (some materials mention IP65 compatibility).

Anti interference capability: Optimize light intensity through saturation exemption function and suppress environmental light interference.

Weather resistance: Made of oil resistant and corrosion-resistant materials, suitable for humid and dusty environments.

4、 Mechanical and structural parameters

Size and weight:

Weight: Approximately 5g, lightweight design.

Size: Specific exterior dimensions can be customized to fit compact devices.

Installation method: Supports flat bracket installation to simplify deployment process.

Material: The base material is plastic, balancing durability and cost-effectiveness.

5、 Function and application parameters

Working mode: Supports standard/high-power dual-mode switching to adapt to different detection distance requirements.

Detection distance: Specific parameters need to be determined based on the fiber amplifier model (such as FS-V30 series).

Application areas: Widely used in the electronics, semiconductor, automotive, food packaging, and biopharmaceutical industries.

Display and operation: Some models support ultra high definition multilingual display screens, improving operational convenience.

Our Services:

1、All our products are new and orginal, and of good quality

2、Our prices are very competitive.

3、 We have a large quantity in stock, so we could help the customers to get the components which are dificult to get.

4、All inquiries will be valued and will reply in 24.

Packing & Delivery:

1、100% brand New and Original Factory Seal!

2、Warranty:1 year

3、Package: Original packing with cartons.

4、Delivery time: Shipped in 3-7 days after payment

5、All the goods will be tested before shipment
