VN-30-L-T6-PI5-VI6-RO2 526132
The Festo brand VN-30-L-T6-PI5-VI6-RO2 526132 model product is a high-performance vacuum generator designed specifically for the industrial automation field. The nominal diameter of its Laval nozzle is 3mm, with a maximum suction flow rate of 339 l/min for the atmosphere. It adopts a T-shaped structure and integrates an open muffler, effectively reducing noise and achieving maintenance free operation. The working pressure range of this product is 1 bar to 8 bar, with a nominal working pressure of 6 bar. It has a large suction capacity and can efficiently generate vacuum through compressed air. It is suitable for automated production lines in multiple industries such as machinery, electronics, packaging, printing, plastics, and robots, meeting the precise requirements for vacuum adsorption, handling, and other processes.
Technical specifcations for VN-30-L-T6-PI5-VI6-RO2 526132
model: VN-30-L-T6-PI5-VI6-RO2
Order number: 526132
Structure and function
Structural features: T-shaped
Integrated function: Open type muffler
Muffler Design: Open Design
Dimensions and specifications
Laval nozzle nominal diameter: 3 mm
Grid size: 24 mm
Vacuum interface: M5
performance parameter
Maximum inspiratory flow rate for the atmosphere: 339 l/min
Working pressure for maximum suction flow rate: 6 bar
Working pressure range: 1 bar to 8 bar
Nominal working pressure: 6 bar
Materials and Sealing
Shell material: POM (polyoxymethylene)
Connecting thread material: anodized refined aluminum alloy
Material of emitter nozzle: refined aluminum alloy
Sealing material: NBR (nitrile rubber)
other characteristics
Features of the injector: large extraction volume, standard type
Applicable scenarios: fields such as machinery, electronics, packaging, printing, plastics, and robots
Advantages: Efficient, clean, economical, suitable for adsorbing fragile, soft, thin non-ferrous, non-metallic materials or spherical objects
This product generates vacuum through compressed air and has the characteristics of high efficiency and stability. It is widely used in industrial automation production lines.
