QSM-G1/8-6-I 186267
Festo QSM-G1/8-6-I 186267 is a G1/8 external thread push in 6mm tracheal quick connector, belonging to the QS series. This model is made of brass material (nickel plated), which has high corrosion resistance and mechanical strength, and is suitable for fast connection of compressed air in industrial automation. Its push-pull design supports tool free installation, automatically locks the trachea after insertion, and can be released by pressing during disassembly, making operation convenient and efficient.
Technical specifcations for QSM-G1/8-6-I 186267
model: QSM-G1/8-6-I
Order number: 186267
Type: G1/8 external thread to 6mm tracheal quick connector
Interface specifications
Gas interface 1: G1/8 external thread
Gas interface 2: suitable for 6mm tracheal outer diameter
Work pressure and temperature
Work pressure range:- 0.95 bar to 14 bar (temperature dependent)
Environmental temperature range:- 10 ° C to 80 ° C
Structure and Sealing
Nominal diameter: 4.1 mm
Sealing method: sealing ring
Structural features: push-pull principle, supports quick installation and disassembly without tools
Material and Protection
Shell material: Nickel plated brass
Release ring material: High alloy stainless steel
Material of tracheal seal: NBR (nitrile rubber)
Material of tracheal clamping element: POM (polyoxymethylene)
Corrosion resistance level: CRC 1 (low corrosion resistance)
Installation method: In line design
