Festo DFSP-50-30-PS-PA Stopper cylinder
Description
stopper cylinder DFSP-50-30-PS-PA Stroke=30 mm, Piston diameter=50 mm, Cushioning=P: Flexible cushioning rings/plates at both ends, Assembly position=Any, Mode of operation=(* single-acting, * pulling action)
Specifications
Manufacturer：Festo
Weight (kg)：2.700000
Item number：DFSP-50-30-PS-PA
Other Reference：DFSP5030PSPA
Other Reference 2：DFSP 50 30 PS PA
Product condition：New
Packing condition：Maxo Packing
Sealed：No
Unit pack：1
Technical Data
Stroke：30 mm
Piston diameter：50 mm
Cushioning：Elastic cushioning rings/plates at both ends
Mounting position：optional
Mode of operation：Single-acting Pulling
Design：Piston Piston rod Profile barrel
Position detection：Via proximity switch
Symbol；00991850
Variants：Piston rod at one end
Protection against torque/guide：Round piston rod
Operating pressure：0.12 MPa ... 1 MPa
Operating pressure：1.2 bar ... 10 bar
Operating medium：Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium：Lubricated operation possible (in which case lubricated operation will always be required)
Corrosion resistance class CRC：2 - Moderate corrosion stress
LABS (PWIS) conformity：VDMA24364-B1/B2-L
Cleanroom class：Class 6 according to ISO 14644-1
Ambient temperature：-10 °C ... 80 °C
Impact force：6280 N
Permissible lateral force during switching operation：1570 N
Max. cycle frequency：5 Hz
Type of mounting：Either:With through-hole Via female thread With accessories
Pneumatic connection：G1/8
Note on materials：RoHS-compliant
Material collar screws：Galvanised steel
Material cover；Wrought aluminium alloy
Anodised：Material seals
TPE-U(PU)：Material piston rod
High-alloy stainless steel：Material roll
Galvanised steel：Material cylinder barrel
Wrought aluminium alloy：Smooth anodised
