On the vast stage of industrial automation, the 1794 series from ALLEN BRADLEY (Rockwell Automation) has become the first choice for countless engineers and technicians due to its exceptional performance, reliable quality, and wide range of applications.

1794-IB32: A Standout in Digital Input Modules

• Number of Input Channels: 32
• Input Voltage Range: 19.2-31.2VDC, with a nominal signal level of 24VDC
• Off-State Voltage: Preferably 5VDC
• Off-State Current: Preferably 1.5mA
• Nominal On-State Current: 1.24mA at 4VDC, with an on-state current range of 2mA-6mA
• FlexBus Current: 5mA at 30VDC
• Isolation Voltage: 50V continuous between the system and field sides
• Thermal Dissipation: Preferably 31.2 BTU/hour at 20.47VDC, or 2W at 6.31VDC
• Operating Temperature: 0 to 55°C
• Storage Temperature: -40 to 85°C
• Vibration: 500G at 5 to 10Hz, with an operating shock of 30G and a non-operating shock of 50G
• Relative Humidity: 5% to 95%, non-condensing

Features:

1. Modular Design: As part of the Flex I/O product series, the 1794-IB32 adopts a modular design, allowing users to flexibly configure and expand based on actual needs.
2. High Reliability: High-quality electronic components and robust hardware design ensure long-term stable operation in various industrial environments.
3. Rich Communication Interfaces: Compatible with Flex I/O communication adapters and various terminal bases, supporting flexible connection and communication methods.
4. Easy Monitoring: Each input channel is equipped with a color status indicator light, facilitating quick identification of active channels and verification of properly functioning input devices.

Characteristics of the 1794 Series

• Beyond the features demonstrated by the 1794-IB32, the 1794 series overall boasts the following notable characteristics:
• High Integration: The series features compact and highly integrated design, making it ideal for applications with limited space.
• Variety of I/O Modules: Offering various types such as digital input/output, analog input/output, special function modules, and communication modules, meeting diverse application needs.
• Powerful Communication Capabilities: Supporting multiple communication protocols including Ethernet, ControlNet, DeviceNet, and EtherNet/IP, facilitating data exchange and communication with other devices and systems.
• Scalability and Flexibility: The modular design allows users to select and add different modules based on system requirements, enabling flexible configuration and expansion of the system.

Application Areas

With its exceptional performance and wide range of applications, the 1794 series plays a pivotal role in industrial control systems. Specifically, it is widely used in the following areas:

• Production Line Control: On automated production lines, the 1794 series modules can efficiently connect PLCs with external devices, enabling real-time monitoring and control of production processes.
• Process Control: In industries such as chemicals and pharmaceuticals, the 1794 series modules can precisely control various process parameters, ensuring the stability and safety of production processes.
• Machine Control: In machinery manufacturing and processing, the 1794 series modules can achieve precise control of machinery equipment, improving production efficiency and product quality.

Product website:

https://www.3splc.com/1794-IB32_c0_ss

As an important component of industrial automation, the ALLEN BRADLEY 1794 series has earned the trust and praise of numerous users with its exceptional performance, reliable quality, and wide range of applications. Whether it's the 1794-IB32 digital input module or other types of I/O modules, the 1794 series contributes significantly to the development of industrial automation with its outstanding performance.
