Allen Bradley 5069-L306ER CompactLogix 600KB Enet Controller Brand new

Allen Bradley 5069-L306ER CompactLogix 600KB Enet Controller

The Allen-Bradley 5069-L306ER is a 5380 CompactLogix controller. This is a Programmable Automation Controller (PAC) with a compact and expandable hardware, used in a wide variety of industrial applications in different industries.

The 5069-L306ER features an embedded 0.6 MB user memory. This memory does not require use of battery as it is equipped with energy storage solution, used for retaining the contents of the user memory without the need of a battery. Additionally, the 5069-L306ER is shipped with a 1784-SD2 Secure Digital (SD) Card with 2GB memory size. This serves as the non-volatile memory and provides convenient method of transferring configuration files and user programs from one controller to another. Optional memory cards may also be used such as 1784-SDHC8 (8 GB), 1784-SDHC32 (32 GB), and 9509-CMSDCD4 (4 GB) CodeMeter CmCard card for increasing non-volatile memory capacity.

The 5069-L306ER supports installation of up to Eight (8) 5069 Compact I/O modules. This compact I/O modules are small form factor I/O that effectively saves panel space, contributing to lowered installation cost of this 5069 controller.

The 5069-L306ER has One (1) USB 2.0 port, capable of transmission speed up to 12 Mbps and Dual Ethernet I/P communication interface supporting linear, star and ring topology. These Ethernet ports is able to exchange data at a transmission speed of 10 / 100 / 1Gbps in full-duplex mode.

The 5069-L306ER is configurable for up to 32 tasks with each task capable of 1000 programs. All event triggers are supported by this controller as well. User programs may be written in Relay Ladder (LD), Structured Texts (ST), Function Block Diagram (FBD) and Sequential Function Chart (SFC) languages.

Technical specifications for 5069-L306ER

Communication Ports：Two (2) Ethernet I/P; One (1) USB

Ethernet performance：10/100/1Gbps

Manufacturer：Rockwell Automation / Allen-Bradley

Product Family：CompactLogix

Product Type：5380 CompactLogix controller

Supported topologies：Linear, Star and Ring

User Memory：0.6 MB Standard;

Non-Volatile memory：1784-SD2 card with 2 GB of available memory (shipped with controller) ; 1784-SDHC8 (8 GB), 1784-SDHC32 (32 GB),and 9509-CMSDCD4 (4 GB) CodeMeter CmCard card.

Maximum number of I/O modules supported：Eight (8) 5069 I/O Modules

No. of Axes：256

Controller Tasks supported：32 Tasks

Programs supported：1000 per task

Brand：Allen-Bradley

Part Number/Catalog No.：5069-L306ER

Module Type：Controller

Application Memory：0.6 Megabytes

Ethernet/IP Nodes：16 Ethernet/IP Nodes

Supported Ethernet/IP Network Topologies：Device Level Ring, Star, and Linear

I/O Expansion：8 I/O

Motion Axes：0 Motion Axes

Programming Languages：Sequential Function Chart, Function Block Diagram, Structured Text, and Ladder Diagram

Dimensions：5.4 x 0.9 x 4.2 in (138 x 22 x 105 mm)

Weight：0.39 lbs (175 g)

Pulse Latching Supported：Yes

Pattern Matching Supported：Yes
