YASKAWA SGDH-30DE-OY New and Original High quality

SGDH-30DE-OY

The SGDH-30DE-OY servo drive is a high-performance and highly reliable industrial automation control equipment designed for medium and large load equipment. Its core advantage lies in supporting three-phase 220V wide voltage input, adapting to SGMAH series 750W to 3kW power range servo motors, and achieving ± 0.01mm level positioning control through high-precision encoder feedback. It is suitable for scenarios such as CNC machine tools and printing machinery that require strict dynamic response. This model adopts modular design, supports mainstream industrial bus protocols such as EtherCAT and MECHATROLINK-II, and has built-in STO safety torque shutdown function, which complies with the IEC 61800-5-2 safety standard. At the same time, it integrates a triple protection mechanism of overcurrent/overvoltage/overheating, with IP55 protection level and wide temperature range operation capability from -10 ℃ to+55 ℃. It has a compact structure, optimized heat dissipation efficiency, supports direct connection/flange dual installation, and can be optionally equipped with a braking resistor module. With SigmaWin+debugging software, it can achieve fast parameter configuration and vibration suppression, and has outstanding performance in high-precision positioning fields such as semiconductor equipment and robot joints.

Technical specifcations for SGDH-30DE-OY

Rated power and voltage:

Applicable motor capacity: This driver can adapt to motors with a larger power range. Although there are differences in the rated power descriptions from different information sources (such as 2.2kW, 2.9kW), the core parameters point to its support for driving medium to large loads.

Power supply voltage: Supports three-phase AC200V input, meets industrial standard voltage specifications, and ensures stable operation of equipment in common industrial power supply environments.

Control and Communication:

Control method: Adopting vector control technology, achieving ± 0.01mm level positioning control through high-precision encoder feedback, suitable for scenarios with strict dynamic response requirements such as CNC machine tools and printing machinery.

Communication Interface: Equipped with MECHATROLINK-III communication command interface, it supports seamless integration with mainstream industrial bus protocols such as EtherCAT and MECHATROLINK-II, meeting the networking requirements of industrial automation systems.

Safety and Protection:

Safety Function: Integrated with IEC 61800-5-2 standard functions such as STO (Safe Torque Off), SS1 (Safe Stop 1), SS2 (Safe Stop 2), SLS (Safe Speed Limit), etc., to ensure the safety of operators and equipment.

Protection mechanism: Built in overcurrent protection, overvoltage protection, and overheating protection triple protection modules, real-time monitoring of system status, effectively extending equipment service life.

Mechanical and installation:

Hardware specifications: Adopting a shelving installation design, the surface has been painted, combining structural strength and protective performance.

Installation method: Supports direct connection or flange installation, adapts to different equipment layout requirements, and provides dynamic brake optional modules to enhance braking performance.

Environmental adaptability:

Protection level: up to IP55 protection standard, can effectively resist dust and liquid intrusion, suitable for harsh industrial environments.

Working temperature: Supports wide temperature range operation from -10 ℃ to+55 ℃, meeting the production needs of multiple regions and seasons.

Certification and Standards:

Safety certification: Complies with the European EC standard EN ISO13849-1 and IEC 61800-5-2 mechanical directive integration requirements, and the product has been tested and certified by authoritative institutions.

Compatibility: Can work together with SGMAH series servo motors (750W to 3kW power range) to form a complete servo drive solution.

Our Services:

1、All our products are new and orginal, and of good quality

2、Our prices are very competitive.

3、 We have a large quantity in stock, so we could help the customers to get the components which are dificult to get.

4、All inquiries will be valued and will reply in 24.

Packing & Delivery:

1、100% brand New and Original Factory Seal!

2、Warranty:1 year

3、Package: Original packing with cartons.

4、Delivery time: Shipped in 3-7 days after payment

5、All the goods will be tested before shipment
