D-C73C
The D-C73C model is a reed type magnetic cylinder induction switch with an IP67 protection level. It adopts a mechanical contact structure and achieves non-contact signal triggering through the linkage of permanent magnets and pistons. It is compatible with dual acting cylinders such as C85 and CDJ2, supports 24V DC/AC and 100V AC wide voltage loads, and can carry a maximum current of 50mA (24V) and 20mA (100V). The built-in LED indicator light can intuitively display the working status. The response time is less than 0.5ms, the voltage drop is ≤ 2.4V, and the working temperature range covers -10 ℃ to+60 ℃. It has a mechanical life of more than 5 million times. The protection level reaches IP67 and can resist dust and water immersion. The product has passed CE certification and is compatible with CG1, NCG and other series cylinders. It can be flexibly installed through steel strip fixation. Widely used in cylinder position detection and stroke control scenarios in automated production lines, material handling equipment, and precision machining equipment.
Technical specifcations for D-C73C
Basic electrical parameters
rated voltage
Supports a wide voltage range of DC5V, 12V, and 24V (compatible with DC4.5~28V), suitable for different industrial control system requirements.
The typical load current is 5-40mA (at 24VDC), with a maximum voltage drop of ≤ 2.4V to ensure signal stability.
Response performance
Response time<0.5ms, meeting the real-time detection requirements of high-speed automation equipment.
The repeatability accuracy reaches 0.005 inches (approximately 0.127mm), ensuring consistency in position detection.
2、 Mechanical and protective parameters
protection grade
IP67 protection standard, can resist dust intrusion and immersion in 1 meter of water for 30 minutes, suitable for harsh industrial environments.
Installation and adaptability
Compatible with C85, CDJ2 and other double acting cylinders, flexible installation is achieved through steel strip fixation.
Supports NCM, CG1, NCG, CJ2, CM2 and other series of cylinders with wide adaptability.
Environmental adaptability
The working temperature range is -10 ℃ to+60 ℃, covering most industrial scenarios.
The mechanical lifespan exceeds 5 million cycles, with an impact resistance of 30g (300m/s ²) and a seismic frequency of 10-55Hz, ensuring long-term reliability.
3、 Function and display parameters
Indication and output
Built in LED indicator light, real-time display of working status.
The control output is NPN/PNP collector open circuit mode, compatible with multiple PLCs and control systems.
Detection characteristics
Based on the principle of magnetic induction, non-contact triggering is achieved through the linkage of permanent magnets and pistons to avoid mechanical wear.
4、 Certification and Standards
compliance
Passed CE certification and meets EU safety standards.
Implement SMC's internal quality management system to ensure product consistency.
