CD85N20-40-B
The CD85N20-40-B model cylinder is a thin double acting cylinder that complies with the ISO 6432 standard. It adopts a single rod double acting design, with a cylinder diameter of 20mm and a stroke of 40mm, featuring a compact structure and lightweight characteristics. It has a built-in magnetic switch interface (compatible with CDQM series magnetic switches) and an elliptical piston design, which can achieve multi-faceted installation and flexible space adaptation. It also supports modular combination with CQS and CQ2 series guide rod cylinders, meeting high-precision positioning requirements (no rotation accuracy below ± 0.2 °). This model adopts a lubrication free design, suitable for air media, with a working temperature range of -10 ℃ to 60 ℃. Its lateral load resistance is 2-4 times higher than the CQ series, and it can directly install loads. It is suitable for industrial scenarios such as automated production lines and precision assembly equipment that require strict space utilization and motion stability. Its steel strip installation type magnetic switch interface (Type B) facilitates users to quickly integrate detection functions.
Technical specifcations for CD85N20-40-B
Basic specifications
Type: Double acting piston rod cylinder, compliant with ISO 6432 standard.
Cylinder diameter: 20mm.
Travel distance: 40mm.
Action mode: single rod double action.
Buffer method: Rubber buffer (some variants may support air buffer, depending on the specific model).
2、 Performance parameters
Using fluid: air.
Maximum operating pressure: 1.0MPa.
Minimum operating pressure: 0.05MPa (some application scenarios support lower pressures, such as 0.08MPa or 0.1MPa).
Pressure resistance test pressure: 1.5MPa.
Piston speed range: 50mm/s to 1500mm/s.
Travel tolerance: 0mm to 1.4mm.
Allowable kinetic energy: 0.27J.
3、 Installation and adaptation
Installation method: Supports multi-faceted installation and is compatible with QS and CQ2 series installation sizes.
Magnetic switch interface: Reserved steel strip installation type (Type B) interface, compatible with CDQM series magnetic switches.
Pipe diameter: The air pressure port is 1/8 inch, and the thread type of the port is G.
Rod end shape: external thread, size M8 × 1.25.
4、 Environmental adaptability
Working temperature range: -10 ℃ to 60 ℃ (for the built-in magnetic ring type, it is -10 ℃ to 50 ℃).
Storage temperature range: -25 ℃ to 85 ℃ (without freezing or condensation).
Environmental humidity range: 10% to 90% RH (non condensing).
5、 Other characteristics
Lubrication requirement: lubrication free design.
Protection level: The IP level is not clearly marked, but the structure has dust-proof capability.
Lateral load capacity: 2-4 times higher than CQ series, can directly install loads.
Magnetic switch configuration: optional magnetic switch (such as D-A73L model), supporting steel strip installation interface.
