SIEMENS 6XV1850-0BT10 New and Original High quality

6XV1850-0BT10

The 6XV1850-0BT10 model product is a Siemens S7-300 series industrial Ethernet communication cable. It adopts a modular structure design and integrates one 9-pin and one 15 pin ITP standard connector, which can achieve efficient interconnection between ITP terminal equipment and industrial Ethernet components. It supports 100 meter standard length transmission and is suitable for data communication of automation control systems in industrial fields such as mechanical manufacturing, chemical engineering, power, and environmental protection. This cable complies with the ITP standard industrial Ethernet protocol, has anti electromagnetic interference capability and industrial grade environmental adaptability, is compatible with Siemens S7-300 series PLC, frequency converter, human-machine interface and other equipment, simplifies the on-site wiring process through prefabricated design, ensures the stability and reliability of industrial site signal transmission, and is a key connecting component for building distributed industrial networks.

Technical specifcations for 6XV1850-0BT10

Basic information

Brand and Model: SIEMENS 6XV1850-0BT10.

Product type: ITP standard industrial Ethernet communication cable.

Application scenario: Suitable for PLC industrial control systems, automation industrial control and other fields, used to connect ITP terminal devices with industrial Ethernet components.

2、 Electrical and transmission characteristics

Transmission frequency: Supports standard Ethernet frequencies.

Cable length: The standard length is 100 meters, which meets the long-distance communication needs of industrial sites.

Electrical data:

Damping per unit length: The maximum is 0.057dB/m at 10MHz, 0.18dB/m at 100MHz, and 0.31dB/m at 300MHz.

Wave resistance: 100 Ω between 1MHz and 100MHz, and still maintains 100 Ω between 100MHz and 300MHz (with a relative symmetry tolerance of 15% to 45%).

Coupling resistance: 2m Ω/m at 10MHz.

Unit length circuit resistance: The maximum value is 124 Ω/km.

Insulation resistance coefficient: 5000G Ω· m.

Working voltage: effective value 165V, maximum value 225V.

3、 Structure and Materials

Structural form: Modular structure, compact design and easy installation.

Conductors and shielding:

Core wire diameter: AWG22 core wire, with a diameter of 0.64mm.

Shielding layer specification: Each core wire is wrapped with overlapping aluminum adhesive foil and covered with an overall shielding braided layer made of tin plated copper wire, providing excellent electromagnetic shielding performance.

Insulation and Sheath:

Core wire insulation material: PE (polyethylene).

Cable sheath material: PVC (polyvinyl chloride), gray black color, meets the requirements for industrial environment use.

4、 Mechanical and installation characteristics

Bending radius: The minimum allowable value for one-time bending is 30mm, and the minimum allowable value for multiple bending is 45mm, suitable for different installation space requirements.

Tensile load: The maximum value is 80N, ensuring that the cable is not mechanically damaged during installation and use.

Installation method: Supports on-site installation for flexible deployment in industrial environments.

Unit length weight: 96kg/km, convenient for transportation and handling during installation.

Our Services:

1、All our products are new and orginal, and of good quality

2、Our prices are very competitive.

3、 We have a large quantity in stock, so we could help the customers to get the components which are dificult to get.

4、All inquiries will be valued and will reply in 24.

Packing & Delivery:

1、100% brand New and Original Factory Seal!

2、Warranty:1 year

3、Package: Original packing with cartons.

4、Delivery time: Shipped in 3-7 days after payment

5、All the goods will be tested before shipment
