SIEMENS 6XV1830-6CH10 New and Original High quality

6XV1830-6CH10

The 6XV1830-6CH10 model product is a bus cable in the Siemens PROFIBUS bus series, designed specifically for industrial automation environments. It uses single or multiple bare copper wires as conductors, paired with PVC sheaths and aluminum-plastic tapes with tinned copper wire braided shielding layers to ensure the stability and anti-interference ability of signal transmission; Its characteristic impedance is precisely controlled at 150 Ω, DC resistance ≤ 57.5 Ω/km, supporting a wide temperature range of -30 ℃ to 70 ℃, and can adapt to extreme industrial environments; This cable supports a maximum transmission distance of 1000 meters for a single line and can be extended to 10000 meters through repeaters, meeting the wiring needs of large factories or distributed control systems. It is widely used to connect PROFIBUS DP master and slave devices and build efficient and reliable industrial communication networks.

Technical specifcations for 6XV1830-6CH10

Conductor: Made of solid bare copper wire conductor, composed of two cores combined in pairs, with red and green core colors, this design is easy to distinguish and connect.

Shielding layer: A double-layer shielding structure is formed by weaving aluminum foil and bare metal wire, which can effectively resist external electromagnetic interference and ensure the stability of signal transmission.

Sheath: Made of PVC outer sheath, it has flame-retardant properties and a purple appearance, which not only provides protection but also facilitates identification.

Compliant with standards: This cable complies with VDE 0472 standard and Class B test (IEC332.1), with reliable quality and guaranteed safety.

Packaging and labeling: Cable straps with meter markings, convenient for users to cut and use according to actual needs. There are various packaging specifications, including 100m, 200m, 300m packaging, as well as 500m and 1000m wooden wheel packaging, to meet the needs of different scenarios.

Working parameters: The maximum specification for single line transmission is 1000 meters. If a repeater is added, it can be extended to 10000 meters. The small order quantity is 20 meters, and it is sold by meter. Users can flexibly purchase according to the specific length requirements of the project.

Connection and assembly: The cable is designed radially symmetrically, allowing for the use of wire stripping tools to quickly and conveniently assemble bus connectors, improving construction efficiency.

Anti interference performance: The overall aluminum foil is woven with tin plated copper wire, which has excellent anti electromagnetic interference performance and is suitable for industrial environments that are susceptible to electromagnetic interference, ensuring that signal transmission is not affected by external interference.

Sheath characteristics: PVC sheath has flame retardant properties, while PUR sheath has excellent mechanical properties, wear resistance, oil resistance, suitable for complex and harsh environments, further expanding the application range of cables.
