SIEMENS 6ES7840-2CC01-0YX0 New and Original High quality

6ES7840-2CC01-0YX0

The 6ES7840-2CC01-0YX0 model product is a programming software authorization specifically designed for S7-200 and S7-200 CN series PLCs. Its core function is the S7-200 PC Access V1.0 OPC server, which supports multi device data exchange through Ethernet, PPI multi master station, MPI, and Modems protocols. This software is compatible with the STEP 7-Micro/WIN programming environment, can synchronously transplant symbol tables to OPC projects, supports up to 8 PLCs for parallel monitoring, and has a maximum connection limit of 4 when using CP cards. Its multilingual interface covers six languages including English, German, and French. The built-in testing client allows for real-time dragging and dropping of variables to the testing window, displaying online values and status intuitively. The software supports standard OPC clients such as VB sample programs, Microsoft Office spreadsheets, and Siemens ProToolPrp, providing detailed help documentation and quick reference guides, and is compatible with the entire range of CPUs from CPU222 CN to CPU226 CN. The system requires Windows 2000/SP4 or Windows XP operating system. It should be noted that this version cannot upgrade early S7-200 OPC related products, and the hardware needs to cooperate with the corresponding communication module to achieve functional expansion.

Technical specifcations for 6ES7840-2CC01-0YX0

Core authorization and compatibility

Authorization Type: S7-200 PC Access V1.0 OPC Server Single Authorization, designed specifically for S7-200/S7-200 CN series PLCs, supporting OPC data exchange.

Compatible with PLC models: Supports the full range of S7-200 CN CPUs such as CPU222 CN, CPU224 CN, CPU224XP CN, CPU226 CN, and is compatible with symbol table porting in STEP 7-Micro/WIN programming environment.

2、 Communication Protocol and Connection Capability

Supported communication protocols:

Ethernet: requires cooperation with CP243-1 or CP243-1 IT communication module.

PPI multi master station: achieved through S7-200/S7-200 CN RS-232/USB cables.

MPI: Using Siemens CP card, up to 4 connections are allowed.

Modes: Supports standards CELL、 Wireless and other types of modems.

Connection ability:

Maximum Connection Count: Up to 8 PLCs can be connected and monitored simultaneously.

CP card restriction: When using a CP card, the number of PLCs connected is reduced to 4.

3、 Software functional characteristics

Multi language support: Supports interfaces in 6 languages including English, German, French, Spanish, Italian, and Chinese, helping the system to be consistent with the interface language.

Built in testing client: supports dragging variables to the testing window, displaying real-time online values and status, simplifying the debugging process.

Example project support: Provide standard OPC client examples such as VB sample programs, Microsoft Office tables, Siemens ProToolPrp, etc., to accelerate project development.

Symbol table migration: The symbol table in STEP 7-Micro/WIN can be seamlessly migrated to PC Access projects, reducing duplicate configurations.

4、 System requirements and compatibility

Operating System: Compatible with Windows 2000/SP4 or Windows XP (Home or Professional) systems.

Incompatibility: Unable to upgrade early S7-200 OPC related products (such as S7-200 OPC server 6ES7810-2MS00-0YX0 and Micro Computing 6ES7810-2MU00-0YX0).

5、 Technical certification and specifications

OPC certification: Through OPC organization certification, it supports any standard OPC client, ensuring the universality and reliability of data exchange.

Protocol package support: Provide complete S7-200/S7-200 CN protocol packages to meet communication needs in different scenarios.
